- Page 1 Installation, Operating, Servicing and Conversion Instructions Silverlink 600 Gas Boiling Tops HT3, HT6 & HT9 Please make a note of your product details for future use: Date Purchased: Number: Dealer: IS513 ECN4287...
-
Page 2: Customer Information
Details are available from your local distributor or direct from us. Used for the purposes for which it is intended, and with careful maintenance as outlined in this User Guide, your Lincat product will give you years of trouble free service. IMPORTANT INFORMATION Please read all of the safety and operating instructions carefully before using this product. -
Page 3: Table Of Contents
CONTENTS Contents Page Customer Information………………………………………………………. 2 Warnings and Precautions………………………………………………… 3 Technical Data……………………………………………………………….. 4 Commissioning………………………………………………………………. 5 Check List of Enclosures………………………………………………….. 5 Serial Number…………………………………………………….………….. 5 Installation…………………………………………………….……………… 6 User…………………………………………………………………………….. 7-9 Servicing ……………………………………………………………………… 10 Conversion…………………………………………………………….……… 11 Spare Parts List……………………………………………………………… 12 Fault Finding…………………………………………………………………. 13 Service information………………………………………………………….. 14 Guarantee………………………………………………………….………….. -
Page 4: Technical Data
TECHNICAL DATA Model Overall Height (mm) Width (mm) Depth (mm) Weight (kg) Total Heat Input Natural (Gross) 9.0kW 18.0kW 27.0kW Total Heat Input Propane (Gross) 9.0kW 18.0kW 27.0kW Total Heat Input Butane (Gross) 7.4kW 14.8kW 22.2kW Gas Inlet Connection ½" BSP (R ½) Supply Pressure - Natural 20mbar... -
Page 5: Commissioning
Pan Supports User Instructions SERIAL NUMBER Each appliance manufactured at Lincat has a unique identifying number found in the NOTE top right hand corner of the data plate attached at the rear of the appliance. Please record that number in the space provided should it be required for future reference. -
Page 6: Installation
INSTALLATION SITING The installer must ensure that all regulations are met and that there is an unobstructed minimum distance of 1000mm from the top of the flue to the ceiling, which must be of non- combustible material. Ensure that all controls have free and easy movement, if not contact a qualified service engineer. -
Page 7: User
USER INSTRUCTION APPLIANCE USE This appliance is only for professional use and should only be used by qualified personnel. Ensure that the person responsible understands how to light, safely operate, clean and shutdown the appliance and is made aware of the position and operation of the gas isolating cock in the event of an emergency. - Page 8 If the appliance has stood unused for any length of time it may be necessary to purge the burner feed pipes of air. To purge the burner feed pipes of air depress and rotate a control knob to the full on position. Maintain the knob in the depressed position for 20- 30seconds and then light the gas at the burner.
- Page 9 CLEANING Do not use a water jet or steam cleaner and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. It is important that users of the appliance systematically check and clean down as necessary areas of the hob that have accumulated oils, fats and other combustible debris from previous cooking.
-
Page 10: Servicing
SERVICING To access parts internally remove the control knobs. Remove the fascia panel securing screws from the underside of the fascia panel. Burner Components To replace the burner and its parts Remove the burner cap 'BU09' Remove the burner head 'BU08' BU09 Remove the 3 screws 'FAS601’... -
Page 11: Conversion
CONVERSION CONVERSION OF GAS TYPE Burner Injector Changes Inlet Part Model Mark Pressure Number 20mbar 1.64 JE155 28-30mbar 0.98 JE157 37mbar 1.10 JE156 Conversion from one gas type to another To convert the appliance from one gas type to another it will be necessary to replace the main burner injectors Ensure the appliance for conversion and all its parts are in a 'cold' state Remove the pan support(s) for ease of access... -
Page 12: Spare Parts List
SPARE PARTS LIST Part number Part description Used on BU07 Burner Body BU08 Burner Head BU09 Burner Cap TC01 Thermocouple FAS351 Burner Gasket FE35 Adjustable Foot JE155 Natural Gas Injector JE156 Propane Gas Injector JE157 Butane Gas Injector PA25 Pan Support MA140 Manifold MA141... -
Page 13: Fault Finding
FAULT FINDING Burner not lighting Turn on gas supply Burner not lighting interlock switch Not all burner ports are lit Burner lights but not all ports are lit Check burner ports for blockages Clean burner ports Call Service Agent Check supply pressure Note: Gas not burning at all the burner ports can occur after a spillage or boil over where water has collected in the burner ports. -
Page 14: Service Information
Gas Appliance Regulations 2016/426. GUARANTEE This unit carries a comprehensive UK mainland warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights. Contact Lincat for terms and conditions The guarantee does not cover: Accidental damage, misuse or use not in accordance with the manufacturer’s instructions ... - Page 15 Notes: IS513 ECN4287 Page 15 of 16...
- Page 16 IS513 ECN4287 Page 16 of 16...
