Installation, Operating, Servicing and
Conversion Instructions
Silverlink 600 Gas Boiling Tops
HT3, HT6 & HT9
Please make a note of your product details for
future use:
Date Purchased:_________________________
Model Number:__________________________
Serial Number:__________________________
Dealer:_________________________________
_______________________________________
IS 513 ECN 3706
Page 1 of 16
Advertisement
Table of Contents
Related Manuals for Lincat Silverlink 600 Series
Summary of Contents for Lincat Silverlink 600 Series
- Page 1 Installation, Operating, Servicing and Conversion Instructions Silverlink 600 Gas Boiling Tops HT3, HT6 & HT9 Please make a note of your product details for future use: Date Purchased:_________________________ Model Number:__________________________ Serial Number:__________________________ Dealer:_________________________________ _______________________________________ IS 513 ECN 3706 Page 1 of 16...
-
Page 2: Table Of Contents
WARNING! This symbol is used whenever there is a risk of personal injury. CAUTION! This symbol is used whenever there is a risk of damaging your Lincat product. NOTE: This symbol is used to provide additional information, hints and tips. -
Page 3: Warnings And Precautions
WARNINGS AND PRECAUTIONS This appliance must be installed, commissioned, serviced and converted by a qualified person in accordance with national and local regulations in force in the country of installation. Strip plastic coating and clean the appliance before use. During operation parts may become hot - avoid accidental contact. Parts protected by the manufacturer shall not be adjusted by the user. -
Page 4: Technical Data
TECHNICAL DATA Model Overall Height (mm) Width (mm) Depth (mm) Weight (kg) Total Heat Input Natural (Gross) 9.0kW 18.0kW 27.0kW Total Heat Input Propane (Gross) 9.0kW 18.0kW 27.0kW Total Heat Input Butane (Gross) 7.4kW 14.8kW 22.2kW Gas Inlet Connection ½" BSP (R ½) Supply Pressure - Natural 20mbar... -
Page 5: Checklist Of Enclosures
CHECK LIST OF ENCLOSURES Model Tick Warranty Card Pan Supports User Instructions IS 513 ECN 3706 Page 5 of 16... -
Page 6: Installation And Commissioning
INSTALLATION AND COMMISSIONING Site this appliance beneath an extraction canopy for the removal of combustion products. Installation must include sufficient ventilation to prevent the occurrence of unacceptable concentrations of substances harmful to health in the room of installation. There must be a minimum free area of 4.5cm per kW of total heat input. - Page 7 knob in the depressed position. When the gas at the burner is burning correctly shut it down and repeat the lighting process for the remaining burners. It is not recommended that a boiling top unit be sited adjacent to either a counter top fryer or a free standing fryer.
-
Page 8: Operating Instructions
OPERATING INSTRUCTIONS Only qualified or trained personnel should use this appliance. LIGHTING SEQUENCE Please ensure that the gas isolation valve for the appliance is turned to the open position before attempting to light this unit. Hob Burners From the OFF position: press and turn the control knob anti-clockwise to any position between the two stylized flames to allow gas through to the burner. -
Page 9: Cleaning
CLEANING Do not use a water jet or steam cleaner, and do not immerse this appliance. Clean all panels with warm water and mild detergent, do not use abrasive materials. Dry with a soft cloth. It is important that users of the appliance systematically check and clean down as necessary areas of the hob and oven cavity that have accumulated oils, fats and other combustible debris from previous cooking. -
Page 10: Servicing, Maintenance And Component Replacement
SERVICING, MAINTENANCE AND COMPONENT REPLACEMENT To access parts internally remove the control knobs. Remove the fascia panel securing screws from the underside of the fascia panel. Burner Components To replace the burner and its parts: BU09 Remove the burner cap 'BU09' BU08 Remove the burner head 'BU08' Remove the 3 screws 'FAS601... -
Page 11: Conversion
CONVERSION CONVERSION OF GAS TYPE Burner Injector Changes Inlet Part Model Mark ∅ ∅ ∅ ∅ Pressure Number 20mbar 1.64 JE155 28-30mbar 0.98 JE157 37mbar 1.10 JE156 Conversion from One Gas Type to Another To convert the appliance from one gas type to another it will be necessary to replace the main burner injectors Ensure the appliance for conversion and all its parts are in a 'cold' state Remove the pan support(s) for ease of access... - Page 12 Bypass Injector Adjustment Remove the control knobs Adjustment for conversion from Natural gas to Propane or Butane: Rotate the bypass injector clockwise full home, do not over tighten. Replace the control knobs Adjustment for conversion from Propane or Butane to Natural gas : Ensure the bypass injector is fully home, do not over tighten Rotate the bypass injector between 1/3 to...
-
Page 13: Fault Finding
FAULT FINDING Burner not lighting Turn on gas supply Burner not lighting interlock switch Not all burner ports are lit Burner lights but not all ports are lit Check burner ports for blockages Clean burner ports Call Service Agent Check supply pressure Note: Gas not burning at all the burner ports can occur after a spillage or boil over where water has collected in the burner ports. -
Page 14: Spare Parts List
SPARE PARTS LIST Part number Part description Used on BU07 Burner Body BU08 Burner Head BU09 Burner Cap TC01 Thermocouple FAS351 Burner Gasket JE155 Natural Gas Injector JE156 Propane Gas Injector JE157 Butane Gas Injector PA25 Pan Support MA140 Manifold MA141 Manifold MA141... -
Page 15: Accessories
ACCESSORIES Part Number Description Used on HT6/SB Splash Back IS 513 ECN 3706 Page 15 of 16... -
Page 16: Service Information And Guarantee
Type number • Serial number • Lincat reserve the right to carry out any work under warranty, given reasonable access to the appliance, during normal working hours, Monday to Friday, 08:30 to 17:00. GUARANTEE This unit carries a comprehensive UK mainland twelve month/2 year warranty. The guarantee is in addition to, and does not diminish your statutory or legal rights.
