The Inlet and Outlet should be as per below
illustration. This will ensure that water will
flow through the filter in an upflow
configuration
NRV Filter
FOLLOWTHE INSTALLATION INSTRUCTIONS CAREFULLY. FAILURE TO INSTALL THE UNIT PROPERLY VOIDS THE WARRANTY.
BEFORE YOU BEGIN INSTALLATION, READ THIS ENTIRE MANUAL. THEN, OBTAIN ALL THE MATERIALS AND TOOLS
PLEASE NOTE:
THE LIFE EXPECTANCY OF THE CARBON MEDIA BED IN THESE UNITS WILL BE REDUCED AS COMPARED TO
A BACK WASHING STYLE CARBON FILTER. THE ACTUAL MEDIA BED LIFE WILL VARY DEPENDING ON WATER CONSUMPTION,
CHLORINE/CHLORAMINES CONCENTRATION AND FLOW RATE. EXCEEDING THE PEAK FLOW RATE LISTED ON PAGE SIX WILL
DRASTICALLY REDUCE THE LIFE EXPECTANCY OF THE CARBON MEDIA.
1. Read all instructions carefully before operation.
2. Avoid pinched o-rings during installaion by applying (provided with install kit) NSF certified lubricant to all seals.
3. This system is not intended for treating water that is microbiologically unsafe or of unknown quality without adequate disinfecion before or after
the system.
INLET
OUTLET
Advertisement
Table of Contents
Related Manuals for Hydrotech NRV TO-150
Summary of Contents for Hydrotech NRV TO-150
- Page 1 The Inlet and Outlet should be as per below illustration. This will ensure that water will flow through the filter in an upflow configuration INLET OUTLET NRV Filter FOLLOWTHE INSTALLATION INSTRUCTIONS CAREFULLY. FAILURE TO INSTALL THE UNIT PROPERLY VOIDS THE WARRANTY. BEFORE YOU BEGIN INSTALLATION, READ THIS ENTIRE MANUAL.
-
Page 3: Table Of Contents
UNPACKING / INSPECTION SAFETY GUIDE PROPER INSTALLATION SYSTEM DIMENSIONS SPECIFICATIONS BEFORE STARTING INSTALLATION INSTALL BYPASS TO THE FILTER INSTALLATION INSTRUCTIONS INSTALLATION PARTS BREAKDOWN TROUBLE SHOOTING WARRANTY... -
Page 4: Unpacking / Inspection
UNPACKING / INSPECTION Be sure to check the entire unit for any shipping damage or parts loss. Also note damage to the shipping cartons. Contact the transportation company for all damage and loss claims. The manufacturer is not responsible for damages in transit. Small parts, needed to install the filter, are in a parts box. -
Page 5: Safety Guide
SYSTEM DIMENSIONS Models A (Inches) B (Inches) C (Inches) 9" NRV TO-100 10" NRV TO-150 NRV TOK-100 9” NRV TOK-150 10” NOTICE - THERE ARE INLET AND OUTLET LABELS ON THE VALVE. PLEASE MAKE SURE TO PLUMB AS... -
Page 6: Specifications
These systems are complete, self-contained, loaded with media and ready to use. A simple inlet and outlet connecion is all that is required for installation. Please review operating pressures, temperatures and water chemistry limitations to ensure compatibility. Specifications NRV TO-100 NRV TO-150 NRV TOK-100 NRV TOK-150 Peak Flow Rates 4.0 gpm... -
Page 7: Install Bypass To The Filter
Where To Install The Filter s Place the filter tank as close as possible to the pressure tank (well s Put the filter in a place where water damage is least likely to occur system) or water meter (city water). if a leak develops. - Page 8 5. Make sure there are no leaks in the plumbing system before proceeding. Close the water tap when water runs clean. 6. Proceed to start up instructions. Note: The unit is not ready for service until you complete the start-up instructions. Note : Carbon filters only: Once the unit has filled sufficiently that water is at least equal to the height of the media shut down the water for 15 –...
-
Page 9: Installation
INSTALLATION Cold Soft Water Electrical Panel Ground Strap Hot Soft Water Ground Strap Raw Water Filtered Water Drain Water Meter Softener NRV Filter Water Heater... -
Page 10: Parts Breakdown
PARTS BREAKDOWN Bypass - 60095097 Model Mineral Tank # (Natural Color) Tank # Tank # Distributor# Valve # Media Tank Size (Black Color) (Blue Color) Bed # NRV-100 9 x 48 25010034 25010036 25010035 50010005 95402 60010068 NRV-150 10 x 54 25010049 25010051 25010050... -
Page 11: Trouble Shooting
TROUBLE SHOOTING A. FILTER BLEEDS TASTE AND ODOR OR SEDIMENT 1. By-pass valve open. Close by-pass valve. 2. Defective or stripped media bed Replace media 3. Quality of water has worsened Have water sample analyzed to determine any change 4. Filter capacity too small Replace with larger unit or add another filter 5. -
Page 12: Warranty
WARRANTY Canature WaterGroup™ warrants that your new water conditioner is built of quality material and workmanship. When properly installed and maintained, it will give years of trouble free service. Five Year Complete Parts Warranty Canature WaterGroup™ will replace any part which fails within 60 months from date of manufacture, as indicated by the serial number, provided the failure is due to a defect in material or workmanship.
