Mobile Instructions
This Document is intended to be a condensed version of the
DC AirCube 500 manual. This is not intended to replace the
full manual for the DC AirCube 500.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the DC 2900c and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dustcontrol DC 2900c

Summary of Contents for Dustcontrol DC 2900c

  • Page 1 Mobile Instructions This Document is intended to be a condensed version of the DC AirCube 500 manual. This is not intended to replace the full manual for the DC AirCube 500.
  • Page 2 Disclaimer Dustcontrol reserves the right to change specifications without notice and is under no obligation to alter previously delivered products. Dustcontrol is not responsible for errors or omissions in this catalogue.

  • Page 3: Table Of Contents

    Content Table of Contents Safety Considerations ............. 4 Technical Data ................ 8 Operation ................9 Service ..................9 Accessories................12 Warranty ................13 Trouble Shooting ..............14 Spare Parts ................15...

  • Page 4: Safety Considerations

    Safety Considerations Read all instructions before attempting to operate this machine and save these instructions. Warning! When using electric machines, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following: 1.
  • Page 5 3. Overload Never let the machine operate fully throttled. Always follow the regulations pertinent to the material you are working with i.e. asbestos. Don´t use the machine for purposes that it isn´t intended for. 4. Body injuries Never let the suction come in contact with parts of the body. The strong suction effect can hurt the blood-vessels in the skin.
  • Page 6 Before further use of the machine it should be carefully checked that the machine is undamaged. If there are any damaged parts these should be repaired by a Dustcontrol authorized service center. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
  • Page 7 Children should be supervised to ensure that they do not play with the appliance. This machine is intended for commercial use only, for example in hotels, schools, hospitals, factories, shops, offices and rental businesses.

  • Page 8: Technical Data

    Technical Data DC AirCube 500 HxWxL (mm/in) 380x340x495 / 15x13.3x19.5 Weight (kg/lb) 13/29 Outlet Ø (mm) Max, Flow (m³/h /cfm) 500/294 Neg. Pressure (Pa/inwg) 400/1.6 Power Consumption (W) Degree of Separation 99.995% (EN 60335-2-69, Class H) Pre-Filter “cartridge” HEPA Degree of Separation HEPA H13 (EN 1822-1) 99.995%...

  • Page 9: Operation

    Operation Connect machine to suitable power source. If extension cord is to be used only waterproof is acceptable. DC Canada recommends cleaning it before the machine is shut down. Machine must be running to preform filter cleaning. To preform filter cleaning first loosen end cuff off tool.
  • Page 10 remove it. Once removed slide a bag over the open end of the unit (if required) remove the old HEPA filter and replace with a new one in the same orientation. Re-clamp on the pre-filter and the process is complete. These simple steps are outlined below.
  • Page 11 Install a new cloth filter with the spines pointing vertically, by tucking the edges under the plastic lip of the filter. These steps are outlined below. Step 1- Remove Dirty Filter Step 2- Reinstall new clean filter Motor Service The fan motor on the DC AirCube 500 requires no service.

  • Page 12: Accessories

    Accessories Description Part No. Hose Ø 125 mm 2420 Hose clamp 4138 Pre-filter 42690 HEPA Microfilter 42692 Funnel 42753 Bracket 42724...

  • Page 13: Warranty

    Normal wear is not covered by this warranty. Service performed by other than Dustcontrol or its authorized agent voids automatically the warranty. No other warranty express or implied is applicable.

  • Page 14: Trouble Shooting

    Trouble Shooting Below is a list of common problems of the machine. If your problem is not found below contact your local Dustcontrol dealer. Problem Fault Solution Machine blows dust. Damaged filter or Change filter. gasket. Machine runs only on Turning power meter is Change power meter.

  • Page 15: Spare Parts

    Spare Parts Below is a simplified parts breakdown of the DC AirCube 500 on the preceding page is a table outlining the parts. Contact your local Dustcontrol dealer or full manual for further spare parts.
  • Page 16 Art No. Description 42320 Switch 42665 Exhaust Flange 42666 Protection Grill 42686 Handle 42690 Pre-Filter 42692 HEPA Filter 42697 Housing Foot 42700 M6 Wing Nut 42713 115V Fan 42749 Fastener 4586 Switch, Speed 4829 400V 4μF Capacitor 80461 Micro Switch 94156 Original Manual...
