- Page 1 Mobile Instructions This Document is intended to be a condensed version of the DC 1800 manual, for field use.
- Page 2 Disclaimer Dustcontrol reserves the right to change specifications without notice and is under no obligation to alter previously delivered products. Dustcontrol is not responsible for errors or omissions in this catalogue.
-
Page 3: Table Of Contents
Content Table of Contents Safety Considerations ............. 4 Technical Data ................ 8 Operation ................9 Service ................... 10 Accessories................12 Warranty ................13 Trouble Shooting ..............14 Spare Parts ................15... -
Page 4: Safety Considerations
Safety Considerations Read all instructions before attempting to operate this machine and save these instructions. Warning! When using electric machines, basic safety precautions should always be followed to reduce the risk of fire, electric shock and personal injury, including the following: 1. - Page 5 3. Overload Never let the machine operate fully throttled. Always follow the regulations pertinent to the material you are working with i.e. asbestos. Don´t use the machine for purposes that it isn´t intended for. 4. Body injuries Never let the suction come in contact with parts of the body. The strong suction effect can hurt the blood-vessels in the skin.
- Page 6 Before further use of the machine it should be carefully checked that the machine is undamaged. If there are any damaged parts these should be repaired by a Dustcontrol authorized service center. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.
- Page 7 Children should be supervised to ensure that they do not play with the appliance. This machine is intended for commercial use only, for example in hotels, schools, hospitals, factories, shops, offices and rental businesses.
-
Page 8: Technical Data
Technical Data DC 1800 HxWxL (mm/in) 740x380x380 / 29x15x15 Weight (kg/lb) 10/22 Hose Length (m) Collecting Container (l) 190/114 Max, Flow (m³/h /cfm) Neg. Pressure (kPa/inwg) 21/84 Power Consumption (W) 1200 1.5/16.2 Fine Filter Area (m²/ft²) Degree of Separation 99.9% (EN 60335-2-69, Class M) 0.85/9.2... -
Page 9: Operation
Connect machine to suitable power source. If extension cord is to be used only waterproof is acceptable. The DC 1800 is equipped with a filter indication lamp alerting you when the filter requires cleaning or changing. Generally the filter should be cleaned once to twice daily. DC Canada recommends cleaning it before the machine is shut down. -
Page 10: Service
The DC 1800 can be used with or without a plastic collection bag. The plastic bag of the DC 1800 should be changed only after filter cleaning. Changing the bag is as simple and only involves un-latching the three container latches, removing and replacing the bag then re-latching the container on. - Page 11 before removing the filter. Check gasket during filter change to ensure good seal is made, if a poor seal is present dust will travel downstream and cause damage to the motor. Fine Filter HEPA Filter...
-
Page 12: Accessories
Turnable end cuff 2114 Ø38 mm chrome wand 7257 Ø38 mm Alu Floor tool 7235 *Note other accessories are available for use with this machine. This list includes all accessories supplied standard with the DC 1800 excluding the 42028 filter. -
Page 13: Warranty
Normal wear is not covered by this warranty. Service performed by other than Dustcontrol or its authorized agent voids automatically the warranty. No other warranty express or implied is applicable. -
Page 14: Trouble Shooting
Trouble Shooting Below is a list of common problems of the machine. If your problem is not found below contact your local Dustcontrol dealer. Problem Fault Solution Motor will not start. Machine not Make sure of connected. connection The motor stops Incorrect fuse. -
Page 15: Spare Parts
Spare Parts Below is a simplified parts breakdown of the DC 1800. On the preceding page is a table outlining the parts. Contact your local Dustcontrol dealer or full manual for further spare parts. - Page 16 Art No. Description 40097 Switch 40453 Filter Cleaning Flap 40524 Guiding Flange 42012 Bottom Cone assembly 4847 Bottom Flap only 4867 Bottom Cone only 42027 HEPA Filter 42029 Fine Filter Cellulose (Standard) 42028 Fine Filter Polyester (optional) 42275 Outlet Channel 42366 Wheelset 42366...
