  • Page 1 SIEMENS 828D/840D OPC/UA Connection 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 2 2. Executing the OPC UA configuration dialog 3. Checking the HMI time 4. Performing a restart In SIEMENS V4.05, there is no user account /password and does not  need to select signature & encryption. The access right of OPC/UA application program (Client) is rights of local machine operator.
  • Page 3 STEP 0: Confirm the right as Manufacturer The operation right is displayed at the bottom left of interface menu. 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 4 STEP 1: Check SIEMENS CNC Version The CNC V4.05 SP03 (or higher) version is needed when using the OPC/UA services. Recommend using V4.07 SP03 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 5 STEP 2: Check OPC/UA Licenses Search “OPC UA”, check “6FC5800-0AP67-0YB0” option and select it. If settings are all done, RESTART is necessary to activate the new settings. 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 6 STEP 3: Setting Network & Firewall option  Setting Address type(Manual-off) IP address assigned Subnet mask assigned 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 7 Company network change:  Select S7 communication(TCP/102)  Select VNC access(TCP/5900)  Select SSH(TCP/22)  Select TCP/4840 (Additional ports) If settings are all done, RESTART is necessary to activate the new settings. 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 8 STEP 4: OPC/UA Setting  Setting Port 4840 (binary protocol)  Setting Admin User, default setting is “OpcUaClient” Hint: Admin User can administrate all OPC/UA account access right.  Setting & confirm Password(Setting Password is necessary  Select Active OPC UA option. 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 9 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 10 STEP 5: Check HMI Date & Time The date & time of OPC/UA must calibration as current date & time  If settings are all done, RESTART is necessary to activate the  new settings. STEP 6: Confirm Network setting 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 11 Must using X130 Ethernet port as connecting with OPC/UA  2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 12  Verify OPC/UA port work or not by using telnet tool. IP address telnet port number EX: telnet 192.167.100.2 4840  Using 3 party OPC/UA software program connect with SIEMENS CNC controller. (Ex. UaExpert software)  WebAccess/CNC connection test. 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 13 STEP 8: SIEMENS CNC Function Pages Position Information Status Display 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 14 Tool List Work Offset 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 15 NC program List System Utilization 2018/9/17 Version: V1.4 Joseph.Sun...
  • Page 16 R Variables Alarm Log 2018/9/17 Version: V1.4 Joseph.Sun...
