Summary of Contents for Renson Fixscreen 100EVO Solar

  • Page 1 Fixscreen Solar ® Montagerichtlinien Installation instructions...
  • Page 2: Table Of Contents

    Fixscreen Solar ® Inhaltsverzeichnis 1 • Allgemeines ............................................2 • Montageart ............................................3 • Befestigung des Kastens ....................................4 • Montage bei Einbauweise 1 ..................................5 • Technische Merkmale ......................................5.1 • Technische Merkmale des Motors ..........................5.2 • Technische Merkmale des Solarpanels ......................
  • Page 3: Allgemeines

    Fixscreen Solar ® 1 • Allgemeines Fixscreen 100 Solar EW1 besteht aus: - Quadratischem Design Kasten mit demontierbarer Tuchwelle mit Motorsteuerung, die direkt an der Konstruktion befestigt wird. - Jedes Screen-System beinhaltet ein Paar identischer Seitenführungen. - Dieses Produkt besteht aus einem Vierkantprofiel unter der Kassette, in der sich die Batterie befindet.
  • Page 4: Befestigung Des Kastens

    Fixscreen Solar ® 3 • Befestigung des Kastens Nehmen Sie den Kasten und legen Sie diese auf eine mobile Werkbank. Öffnen Sie den Kasten, nach Entfernen Sie die Abdeckscheibe für das Kabel, durch die dem Sie die zwei Schrauben Schrauben zu lösen. Im Kasten befinden sich 2 Tuchwellen- entfernt haben.
  • Page 5: Montage Bei Einbauweise 1

    Fixscreen Solar ® 4 • Montage bei Einbauweise 1 Beim Fixscreen 100 Solar EW1 ist ein Anschluss ans Stromnetz nicht erforderlich. • Bei der Installation der Führungen muss der Kasten bereits auf den Führungen sitzen. • Verwenden Sie einen Sechskantschlüssel 3 um die Vorderseite der Seitenführung zu demontieren.
  • Page 6 Fixscreen Solar ® Montage Rückseite (ø 5mm) Seiltiche Montage (ø 5mm) Die G-Führung (geschlossen) ist Standard vorgebohrt (Diameter 10). Stufenlochbohrung ist in Option. Es gibt 2 Einstellungsmöglichkeiten für die Seitenführungen: an die Seitenwand oder die Rückwand. Das Bohrloch Diameter 10 ist schon vorgebohrt, das Bohrloch Diameter 5 muss bauseitig noch gebohrt werden.
  • Page 7 Fixscreen Solar ® Wenn der Kasten bereits definitiv an der ihn umgebenden Struktur befestigt wurde, muss man die Tuchrolle entlang der Innenseite einbringen. Hierfür am besten mit 2 Personen arbeiten! Unterstützen Sie dabei die Endschiene! Befestigen Sie die Abdeckscheibe mit den 2 Torx-Schrauben mit dem Werkzeug T20 wieder an der Kassette.
  • Page 8 3) Nie Stoffe auf die Photovoltaikzellen der Solarpanels bringen, die die Sonnenstrahlung filtern können (z.B. Farbe). Geografischer Einsatzbereich Jede Verwendung, die nicht dem von Renson bestimmten Anwendungsbereich entspricht, gilt als ISLAND nicht bestimmungsgemäß. Im Falle einer nicht bestimmungsgemäßen Verwendung, wie auch bei Nichtbefolgung der Hinweise in unserer Anleitung, entfällt die Haftung und Gewährleistungspflicht...
  • Page 9: Technische Merkmale

    Fixscreen Solar ® 5 • Technische Merkmale 5.1 • Technische Merkmale des Motors Spannungsversorgung 12 V DC (min 11,5 V, max 14 V) Funkfrequenz 433,42 MHz Schutzart IP 44 normal -10°C / +40°C und kurzfristig -20°C / Temperaturbereich +60°C Max. einlernbare RTS Funksender Max.
  • Page 10: Endabstellung

    EINE ENDABSCHALTUNG MUSS ABER VOM INSTALLATEUR NOCH EINGESTELLT WERDEN! Die Endpunkte (oben und unten) wurden von Renson eingestellt. Der oberen Endpunkt: Wurde von Renson eingestellt wobei die Endschiene, inkl. Abdichtungslippe, nicht mehr sichtbar ist. Eine Endabschaltung muss aber vom Installateur noch eingestellt werden. Abschaltung unterer Endpunkt: Der untere Endpunkt wurde eingestellt bis zu 400 mm von der Kassettenunterseite.
  • Page 11: Endkontrolle Der Screen

    Fixscreen Solar ® 7 • Endkontrolle der Screen ➊ Bevor Sie den Motor anschalten, bitte die rechtwinklige Montage überprüfen.Die Diagonale (D1 und D2) und die Parallelen (H1 und H2) müssen identisch sein, um ein gutes Abrollen der Screens zu gewährleisten D1 = D2 und H1 = H2 ➋...
  • Page 12: Wartung

    Standards hergestellt werden. • RENSON übernimmt keine Verantwortlichkeit/Garantie falls die Motoren anders angesteuert werden als von Somfy angegeben. • RENSON übernimmt dazu keine Garantie das Protokol der Screenmotoren sei kompatibel zu Automatisation/Domotik. • Geringfügige Abweichungen zwischen den Farbmustern und den Profilen des Sonnenschutz-Screens können im Herstellungsprozess auftreten.
  • Page 13: Einstellung Produkt

    Fixscreen Solar ® 9 • Einstellung Produkt Ihr Screen kann vollständig recycelt werden. Informieren Sie sich bei Ihrer Stadt oder Recycelstation über die lokalen Umweltauflagen. Beim Demontieren des Screens sollen Sie die Installation spannungslos machen. Materialien sollen getrennt werden bei der Vernichtung des Produktes. Brennbare Materialien sollen von nicht brennbaren Materialien getrennt werden bei der Vernichtung des Produktes.
  • Page 14 Fixscreen Solar ® Table of contents 1 • General ............................................... 2 • Installation method ......................................3 • Preparation of the empty box ................................4 • Installation method 1 ....................................... 5 • Technical specifications .................................... 5.1 • Technical specifications of the motor .......................
  • Page 15: General

    Fixscreen Solar ® 1 • General Fixscreen 100 Solar IM1 consists of : - Square box, with demountable fabric roller motor controlled, which is directly fixed against the construction. - Each screen has a pair of identical side channels. - This product consists of a rectangular profile below the cabinet containing the battery. - Screen of high-value polyester or glass fibre fabric, with Fixscreen technology (wind tight technology thanks to the combination of a symmetrical zip and a patented wear-resistant H-PVC inner-rail).
  • Page 16: Preparation Of The Empty Box

    Fixscreen Solar ® 3 • Preparation of the empty box Place the box on a mobile workbench. Demount the cover plate Remove the shield plate for the cable, by unscrewing the from the box, by unscrewing screws. In the box you will find 2 guiding pieces at each end 2 screws, on both ends of of the fabric roller, fixed with a couple of screws.
  • Page 17: Installation Method 1

    Fixscreen Solar ® 4 • Installation method 1 With the Fixscreen 100 Solar IM1, no connection to the mains power supply is required. • Demount the 2-part side channel. • Use an Allen key type 3 for unscrewing the front part of the side channel type ‘G’.
  • Page 18 Fixscreen Solar ® Mounting of side channel Mounting of side channel sideways (ø5mm) through the backside (ø5mm) The closed type side channel is pre-drilled as standard (the inner chamber by Ø10 mm in all cases). There are 2 placement options for the side channel: sideways or via the rear wall. The Ø10 mm borehole is already pre-drilled;...
  • Page 19 Fixscreen Solar ® If the box is completely fixed (on the structure), you need to mount the fabric roller. You need to do this with two persons! Support the bottom bar while doing this. Put the shield plate back in the cabinet with the 2 Torx screws using tool T20. Make sure the shield plate avoids contact between the cable and the fabric roller.
  • Page 20 In this event, as for all usage not consistent with the instructions ICELAND in the installation manual, Renson accepts no responsibility for harm or damage and the optimal functioning cannot be guaranteed. S W E D E N...
  • Page 21: Technical Specifications

    Fixscreen Solar ® 5 • Technical specifications 5.1 • Technical specifications of the motor Power supply 12 V DC (min 11,5 V, max 14 V) Radio frequency 433,42 MHz Index protection rating IP 44 Operating temperature -10°C / +40°C and exceptionally -20°C / +60°C Maximum number of connected RTS control points Maximum number of connected sensors...
  • Page 22: Motor Adjustment (Upper/Lower Limits)

    The upper and lower end point is adjusted in the factory. Adjusting upper end point: The upper end point is adjusted in the factory of Renson. The bottom bar including sealing strip will no longer be visible. Adjust the upper end point for end use.
  • Page 23: Final Check Of The Screen

    Fixscreen Solar ® 7 • Final check of the screen ➊ Before starting the motor, check if the set-up is square. The diagonals (D1 and D2) and parallels (H1 and H2) should be as equal as possible for the fabric to properly unwind.
  • Page 24: Maintenance

    • The main connection should be made by a qualified electrician in accordance with applicable standards. • RENSON does not take the liability or gives the warranty on the automatic control system for the motor screen, except the well-known systems of Somfy.
  • Page 25: Discard Of The Product

    Fixscreen Solar ® 9 • Discard of the product Your screen can fully be recycled. You should inform yourself about the environmental regulations in your city or recycling station. If you demount your screen, it should be tensionless. The materials should be separated by the product’s destruction. Combustible materials should be separated from non-combustible materials by the product’s destruction.
  • Page 26 Fixscreen Solar ®...
  • Page 27 Fixscreen Solar ®...
  • Page 28 Recht vor, technische Änderungen an den im Folgenden behandelten Produkten ® vorzunehmen. Die meist aktuelle Version dieser Broschüre kann aufgeladen werden von w w w.renson.eu Renson reserves the right to make technical changes to the products shown.
