  • Page 1 Smart AC application MIM-H03 Multi Wi-Fi kit user & installation manual imagine the possibilities Thank you for purchasing this Samsung product.
  • Page 2: Table Of Contents

    Specification of wired/wireless router for Samsung Smart Air conditioner....... . .
  • Page 3: Safety Precautions

    Safety precautions This installation manual explains how to install a Wi-Fi kit to an indoor unit of Samsung system air conditioners. Read the installation manual thoroughly before installing the Wi-Fi kit. (Refer to the appropriate manual for installing product or other optional parts.) WARNING Hazards or unsafe practices that may result in severe personal injury or death.
  • Page 4: Check Before Installing Wi-Fi Kit

    Check before installing Wi-Fi kit Parts Assy Wi-Fi kit Cable tie (2) Cable clamp (3) M4×16 screw (5) User & Installation manual U- terminal (6) • Wi-Fi kit should be installed by a certified installer. • Before installing a Wi-Fi kit, you should check whether the power of the kit is turned off. CAUTION •...
  • Page 5: How To Install Wi-Fi Kit

    How to install Wi-Fi kit Wi-Fi kit installation • For smooth operation, install the Wi-Fi kit and the wireless router in open space with no obstacles between them. Operation may not be possible if the distance between the Wi-Fi kit and the wireless router is too far or if there's any CAUTION obstacle between them.
  • Page 6 How to install Wi-Fi kit 3. Use two or more screws to fix the rear cover of the Wi-Fi kit to a wall. Then, connect the power cable (V1, V2) and the communication cable(F1, F2) to the terminals on the back of the front cover in appropriate length. 4.
  • Page 7 5. Reassemble the Wi-Fi kit. • Put the front cover of the kit into the upper grooves first and then fit it as shown in the picture. After assembling the Wi-Fi kit, please check if there is any gap because of the connection cable between NOTE front cover and rear cover.
  • Page 8 How to install Wi-Fi kit ❋ ❋ If an indoor unit does not have V1 and V2 terminal block, use the SUB PBA (sold separately) to supply power to the Wi-Fi kit. SUB PBA (MIM-A00) 12 V COM2 ORG : Connect the ORG wire to V1 RED : Don’t use it YEL : Connect the YEL wire to V2 BLU : Don’t use it...
  • Page 9 • When installing a Wi-Fi kit with 10 m (32.8 feet) or more wire, the communication wire and power wire of a Wi-Fi kit should be installed separately. (The Wi-Fi kit will malfunction because of electrical fault. ) CAUTION • When installing a Wi-Fi kit on the wall, select proper thickness of wires in the consideration of the hole size for wire on the wall.
  • Page 10: Checking The Wi-Fi Kit

    How to install Wi-Fi kit Checking the Wi-Fi kit Power LED Wi-Fi Connect LED Wi-Fi Configure LED AP Button Reset <Wi-Fi kit front view> LED display information LED information Power Wi-Fi Connect Wi-Fi Configure Initialized Normal AP Connection OK. But, Internet is not Blinking Connected Air conditioner...
  • Page 11: Initializing User Data

    Initializing user data f If you want to initialize all the user data to set the Wi-Fi kit as factory default status, press and hold the button (SW3) inside the Wi-Fi kit for 5 seconds. After releasing the button, all the lamps on the Wi-Fi kit are turned on and all the user data is deleted.
  • Page 12: Setting The Network

    Wi-Fi kit supports Wi-Fi 2.4 GHz only. f Wi-Fi kit supports the IEEE802.11 b/g/n communication protocol. (Samsung Electronics recommends use of IEEE802.11n.) f If the wired/wireless router is not Wi-Fi certified product, it may not be connected to the Wi-Fi kit.
  • Page 13: Starting Samsung Smart Home App

    If you are a Samsung Smart phone user, you can automatically log on to the App with the Samsung account. f If you are not a Samsung Smart phone user, the login page appears every time you use the Samsung Smart Home App.
  • Page 14: Starting System Air Conditioner App

    Starting System Air conditioner App Controlling the air conditioner with Samsung Smart Home app f You can skillfully control the air conditioner. Category Control items Description All On/Off Turn all devices on or off On/Off Turn an indoor unit & ERV & DHW on or off.
  • Page 15: Troubleshooting

    Wi-Fi kit blinks. work. Check whether all the lamps of the The Wi-Fi kit has a problem. Contact the Samsung service center. Wi-Fi kit blinks. The Wi-Fi kit is not correctly connected to the indoor unit. Contact Check whether the lamp of Wi-Fi the Samsung service center.
  • Page 16: Specifications

    The software included in this product contains open source software. You may obtain the complete corresponding source code for a period of three years after the last shipment of this product by sending an email to mailto:oss.request@samsung.com. It is also possible to obtain the complete corresponding source code in a physical medium such as a CD-ROM; a minimal charge will be required.
  • Page 17 Επιλέξτε Υποστήριξη > Αναζήτηση υποστήριξης προϊόντος και εισαγάγετε το όνομα μοντέλου. Par la présente, Samsung Electronics déclare que cet appareil de type équipement radio est en conformité avec la Directive 2014/53/UE. Le texte intégral de la déclaration de conformité de l'UE est disponible à l'adresse Internet French suivante :...
  • Page 18 Treść oficjalnej deklaracji zgodności jest dostępna pod adresem http://www.samsung.com w menu Wsparcie > Szukaj, gdzie należy podać nazwę modelu. Pelo presente, a Samsung Electronics declara que o aparelho tipo equipamento de rádio está em conformidade com a Diretiva 2014/53/UE. O texto integral da declaração de conformidade europeia está disponível no seguinte Portuguese endereço da internet:...
  • Page 19 розділу підтримки, потім — до поля пошуку підтримки для певного виробу та введіть назву моделі. Ovim putem kompanija Samsung Electronics izjavljuje da je ovaj uređaj u tipu radio opreme u skladu sa direktivom 2014/53/EU. Kompletan sadržaj EU deklaracije o usaglašenosti dostupan je na sledećoj internet adresi: Serbian Zvaničnu deklaraciju o usaglašenosti možete naći na adresi http://www.samsung.com, idite na Podrška >...
  • Page 20 (Name and signature of authorized person) ※ This is not the address of Samsung Service Centre. Please see the address or the phone number of Samsung Service Centre in the warranty card or contact the retailer where you purchased your product.
  • Page 21 MEMO...
  • Page 22 Smart air conditioner APP can be altered without notice for quality improvement and also be deleted depending on the circumstances of manufacturing firms.
