Summary of Contents for Fiilex Q1000 II
-
Page 1: User Manual
Q1000 II FLXQ1G2 User Manual 190322A3... -
Page 2: General Notes
The Q1000 II can be mounted to baby and/or junior stands with the (7) Junior Pin Receiver. Secure the light by tightening the Stand Locking Pin (8). • Positioning the Q1000 II Loosen the Yoke Knob (10) to adjust the Q1000 II to the desired position. Tighten the Yoke Knob (10) to secure. • DMX Interface The Q1000 II connects to DMX signals via 5-pin XLR ports. - Page 3 Knob (10) to adjust USB Port (18) for Power Input (19). diameter of the Light sliding into Accessory the Q1000 II to the updating the Plug the AC Source (5). Fiilex Holder (3). Closing desired position. Turn firmware.
- Page 4 Address Knob to set the address. The new selected address will auto- matically set after 3 seconds of inactivity. 4. When a DMX address is selected, the Q1000 II will automatically assign the next two addresses in the following order:...
-
Page 5: Mounting The Power Supply
Mounting the Power Supply Option 1: Attach Power Adapter to Clamp Option 2: Attach Power Adapter to Yoke Specifications CCT Range 2800-6500K Continuous Tuning Light Engine Dense Matrix LED Power Draw 320W AC Max DC Input 48V DC (300W DC Max) AC Input 100 - 240V AC, 50 ~ 60Hz (120V~ 60Hz for US) Power Port... - Page 6 • CAUTION! High Beam Intensity! - Do NOT look into the Light Source (5) of the fixture. • DO NOT point the light at combustible or flammable materials. • DO NOT attempt to disassemble the body of Q1000 II. Doing so will void the warranty. • DO NOT cover/block the side and back air vents.
