- Page 1 C360 Series FLXC360 FLXC365 User Manual 190103A2...
-
Page 2: General Notes
• Powering On The C360 Series comes with its own integrated Power Module Box (8). To supply a C360 Series fixture with power, plug the power cord into a power outlet. The fixture’s OLED Display (19) will turn on once it is receiving power. The On/Off Button (15) can toggle the fixture’s output on and off. -
Page 3: Parts Diagram
Parts Diagram 1. Barndoor Brackets 2. Yoke Knob 3. Barndoor Lock 4. Magnetic Accessory Lock 5. Side Vents 6. Size M12 Screw Receiver 7. Power Cord 8. Power Module Box 9. 5” Fresnel Zoom Lens (C365 only) 10. Lens Tighten Knobs (C365 only) 11. -
Page 4: Rear Panel Interface Operation
1 second of inactivity. 4. The C360 Series fixtures occupy three consecutive DMX channels for operation. For example, with a base DMX address of 50, the controls for intensity, CCT, and hue will correspond to DMX channels 50, 51, and 52 respectively. -
Page 5: Warranty
Safety • Do NOT attempt to disassemble the body of the C360 Series. Doing so will void the warranty. • Do NOT submerge the C360 Series Fixtures in water. • Do NOT cover/block the side and back air vents. • Use only a soft, dry towel to gently clean the exterior of the light.
