Page 1: User Manual
FLXQ8JR User Manual 190103A2... -
Page 2: General Notes
• DMX Interface The Q8 Junior is equipped with two DMX interfaces. RJ45 (17) or XLR Ports (16 & 21) are used to send the DMX signal to the lamp head. Both interfaces include in/out ports for the purpose of daisy-chaining the DMX line through to the next lamp head. -
Page 3: Parts Diagram
Adjusting the USB Interface Powering On Mounting Accessories Securing Accessories Q8 Junior The Q8 Junior is Insert the powerCON Slide the Top Latch (3) Flip down the Top equipped with a mini connector into the to the right and flip it... -
Page 4: Rear Panel Interface Operation
Address Knob to set the address. The new selected address will auto- matically set after 3 seconds of inactivity. 4. When a DMX address is selected, the Q8 Junior will automatically assign the next two addresses in the following order:... -
Page 5: Warranty
• Before first use, make sure to remove all protective membranes. • Do NOT use the gel holder designed for the P series of lights with the Q8 Junior. • Do NOT mount the Q8 Junior in a hanging position without a separate safety cable.
