Fiilex T360 Series User Manual

Advertisement

T360 Series
FLXT360
FLXT365
User Manual
190103A2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T360 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Fiilex T360 Series

  • Page 1 T360 Series FLXT360 FLXT365 User Manual 190103A2...
  • Page 2: General Notes

    (510) 620-5155. • Powering On The T360 Series comes with its own integrated Power Module Box (6). To supply a T360 Series fixture with power, insert the Eutrac Multi-Adapter (18) into a Eutrac system. The fixture’s OLED Display (17) will turn on once it is receiving power.
  • Page 3: Parts Diagram

    Parts Diagram 1. Barndoor Brackets 2. Yoke Knob 3. Barndoor Lock 4. Magnetic Accessory Lock 5. Side Vents 6. Power Module Box 7. 5” Fresnel Zoom Lens (T365 only) 8. Lens Tighten Knobs (T365 only) 9. Barndoor Brackets (T365 only) 10.
  • Page 4: Rear Panel Interface Operation

    1 second of inactivity. 4. The T360 Series fixtures occupy three consecutive DMX channels for operation. For example, with a base DMX address of 50, the controls for intensity, CCT, and hue will correspond to DMX channels 50, 51, and 52 respectively.
  • Page 5: Warranty

    Fiilex guarantees, to the original buyer, that this product is to be free of defects in both workman- ship and material for a period of one year from the date of shipment. This warranty extends to all products which have proved defective through normal use but excludes products that have been disassembled, modified or misused by the buyer or any other person.

This manual is also suitable for:

Flxt360Flxt365
