Page 1: User Manual
RGBW FLXMXRGBW User Manual 190102A2... -
Page 2: General Notes
(refer to Parts Diagram on following page) • Powering On The Matrix II RGBW power adapter includes an AC plug for power input and a 3-pin XLR connec- tor for output. To supply the fixture with power, insert the XLR connector into the Power Input (19) and connect the AC plug into an active wall socket. -
Page 3: Parts Diagram
Parts Diagram Top Handle Heat Exhaust Vent Top Accessory Latch Bottom Accessory Latch Baby/Junior Pin Mount Tightening Knob Yoke Yoke Tightening Handle OLED Display Lock/Menu Dial Mini USB Port (firmware update) On/Off Switch Intensity Dial Gain/Saturation Dial CCT/Hue Dial Fan Intake Vent USB Port (5V 1A power) DMX Output (5-Pin XLR-Female) -
Page 4: Rear Panel Interface Operation
3. Lock in setting by clicking knob once. Alternatively, the address will automatically lock in after 1 second of inactivity. 4. The Matrix II RGBW occupies a variable amount of DMX channels depending on mode. When a DMX address is selected, the Matrix II... -
Page 5: Mounting The Power Supply
Mounting the Power Supply Option 1: Attach Power Adapter to Clamp Option 2: Attach Power Adapter to the Yoke Specifications CCT Range 2800 - 10000K Continuous Tuning Light Engine (Four) Dense Matrix LED Power Draw 340W Max 48V (300W DC Max) DC Input 100 - 240V AC, 50 ~ 60Hz AC Input... -
Page 6: Warranty
• CAUTION! High intensity output! - Do NOT look directly into light source. • DO NOT point the light at combustible or flammable materials. • DO NOT attempt to disassemble the body of the Matrix II RGBW. Doing so will void the warranty.
