Hot buffet
... with bain-marie
...with Ceran hot plates
...with built-in system carrier for varithek
Cold buffet
...with refrigerated well
...with refrigerated cabinet
Drinks buffet
Neutral buffet
Niche buffet
Drive-in buffet
Cash till buffet
Corner buffet
Tray/cutlery buffet
Tops
Shelves
The illustrations show design and configuration examples, which do not necessarily have to be included in the scope of
delivery.
Observe the operating instructions
Translation of the Original Operating Instructions
DOWNLOAD: USER MANUAL
QR code on type plate
Issue: 2018-08-01
®
systems
Rolling Buffet
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Rieber Rolling Buffet Series
Summary of Contents for Rieber Rolling Buffet Series
- Page 1 Hot buffet … with bain-marie …with Ceran hot plates ® …with built-in system carrier for varithek systems Cold buffet …with refrigerated well …with refrigerated cabinet Drinks buffet Neutral buffet Niche buffet Drive-in buffet Cash till buffet Corner buffet Tray/cutlery buffet Tops Shelves The illustrations show design and configuration examples, which do not necessarily have to be included in the scope of...
-
Page 2: Table Of Contents
10.1 Notes on troubleshooting ............................ 33 10.2 Disposing of your product ........................... 34 11 Warranty and liability ............................ 35 12 Excerpt from EC Declarations of Conformity ..................... 35 13 Contact address ............................36 14 Appendix ................................ 36 Rieber GmbH & Co. KG... -
Page 3: Revision Index
If there are any shortcomings in your opinion, please do not hesitate to let us know. With your help, we will try to become even better. Please directly contact Elemente@rieber.de info@rieber.de Please add your notes here Rieber GmbH & Co. KG... -
Page 4: Representation Conventions In The Text
Failure to follow these warning instructions may cause serious bodily injury or even death. CAUTION indicates a potentially harmful situation. Failure to follow these warnings may cause minor bodily injury. Rieber GmbH & Co. KG... -
Page 5: General Safety Instructions
Make sure the appliance cannot be switched on unintentionally. Double check that the main switch is in the "OFF" position before inserting the plug in the socket. Connecting the appliance to the power supply while it is switched on can cause an accident. Rieber GmbH & Co. KG... -
Page 6: Operator's Duties
In addition, the operator must train the personnel and inform them of the hazards involved at regular intervals. The operator must provide the personnel with the necessary protective equipment and issue mandatory instructions on wearing it. Rieber GmbH & Co. KG... -
Page 7: Personnel Qualification Requirements
Work on the cooling unit should only be carried out by authorised skilled personnel like a refrigeration specialist or a member of the Rieber Customer Service. Any repairs and/or overhaul during the warranty period may only be carried out by the Rieber Service Department. -
Page 8: Appliance-Specific Safety Instructions
Carry out transport with an adequate number of people. Only move the rolling buffet using the casters. Secure the buffet against inadvertently rolling away with the ‘parking brake’. Wear safety shoes to prevent injuries. Rieber GmbH & Co. KG... - Page 9 When using the buffet with ‘accessories’, other risks may arise. Children may not play with the buffet. Cleaning and user maintenance may not be carried out by children without supervision. Rieber GmbH & Co. KG...
-
Page 10: Instructions On Behaviour In An Emergency
The type plate provides important technical data for use and a unique identification, which is necessary for replacement and wear parts, for example. Some appliances also have symbols/pictograms. Inspect the product identification for legibility. Please contact us at www.rieber.de if necessary Examples OPEN... -
Page 11: Designated Use
Transport the buffet horizontally, as in its working position. Do not use aids such as forklift trucks to unload the buffet from the pallet, as this may cause damage. Page 13 Rieber GmbH & Co. KG... -
Page 12: Description Of Appliance
Area for connecting (screw connection) the buffet and for screwing on the tray slide /plate holder. Top with light/heating Fold-down tray slide Front panel Protection class IPX0: No protection against water Refrigerant: R134a, R404a, R452a Example Operating and display elements Rieber GmbH & Co. KG... -
Page 13: Useful Information From Delivery Through To Initial Cleaning
Wear protective gloves and safety shoes. ► Lift the buffet with the necessary number of people. Another person quickly pulls the pallet together with the 2 profiles away. Example # First cleaning See ‘Cleaning, Maintenance and Care’, page 26 Rieber GmbH & Co. KG... -
Page 14: Information On Connecting The Buffet
When electrically bridging the buffet with a connecting cable, make sure the cable end is securely fixed. Fix the cable end by hand in the fixing bracket on the underside of the buffet. ► Do not let the cable hang down. Keep the buffet away from moisture. Rieber GmbH & Co. KG... - Page 15 230 V /16 A, around 3 m 33 10 33 02 CEE plug 400 V /16 A, around 3 m 33 10 33 01 Coupling 33 10 3306 Coupling 33 10 3307 More: See operating instructions appendix "Rolling Buffet Electrical Connectors" Rieber GmbH & Co. KG...
-
Page 16: Instructions For Use
Connect the buffet to a socket with a series-connected residual current operated device (RCD) with a tripping current of 30 mA. A qualified electrician can technically assess the need for potential equalisation. Have potential equalisation carried out by a qualified electrician if necessary. Rieber GmbH & Co. KG... - Page 17 Risk of a cable fire. Peak currents occur if lots of connectible electrical appliances are switched on and off simultaneously along the chain. ► Do not switch lots of appliances on and off simultaneously. ► Only pull out the mains plug after switching the appliance off. Rieber GmbH & Co. KG...
-
Page 18: Instructions For Use Of The Hot Buffet
8.2.1 Bain-marie Observe the prerequisites Intended for use with Gastronorm containers from Rieber. The wells can be heated wet or dry. The wells should preferably be heated wet. The water bath enables even distribution of the heat. Examples The well is equipped with a water drain tap. - Page 19 User tip Seal GN container with a lid. GN containers are standardised but do not generally fit into one another. ► Use GN containers with lids from Rieber. ▌ This saves on energy and electricity costs. Rieber GmbH & Co. KG...
- Page 20 CAUTION When working in the area of the Ceran hot plate or heating surface and the glass hot plate from Rieber there is a risk of burning one's hands and arms on hot surfaces up to +60 °C. On the top with light/heating there is a risk of injury in the area of light sources and the heated top surface.
- Page 21 Intended for use with varithek 2.0 from Rieber. Observe the instructions in the relevant operating manual. ® varithek 2.0 operating instructions from Rieber WARNING Risk of burns. Risk of overheating. Always leave the system module flap open on an appliance with inductive heating.
- Page 22 Supplement your top with light/heating with a contact guard. Contact guard for: Order no. Buffet length 1270 mm 73 70 04 01 Buffet length 1770 mm 73 70 04 02 Buffet length 2270 mm 73 70 04 03 Rieber GmbH & Co. KG...
-
Page 23: Instructions For Use Of The Cold Buffet
With circulating air cooling, automatic defrosting and defrost water evaporation. Thermostat with digital display, ON/OFF switch; Refrigeration range +5 °C to +15 °C Operator side: Guest side: Sliding doors Flaps open Swing doors Air flow in the cabinet Rieber GmbH & Co. KG... - Page 24 The green rocker switch lights up. ▌ The display on the controller indicates the ACTUAL temperature. ▌ The cooling operation display (2) lights up during the cooling process. Pre-cool the appliance before filling if possible, for around 20 minutes. Rieber GmbH & Co. KG...
- Page 25 ▌ The green rocker switch is off. Empty display, no LED will light up. The appliance is off. Pull out the electrical connection plug and place in the holder. ▌ The appliance will defrost. Rieber GmbH & Co. KG...
-
Page 26: Cleaning, Maintenance And Care
Avoid extended exposure of stainless steel to liquid containing salt, as this can lead to surface discolouration and corrosion. ► Avoid direct, extended contact of stainless steel with corroding iron parts, e.g. cast iron pans or steel kitchen sponges. Source: DGUV Regulation 3. Electrical Systems and Equipment Rieber GmbH & Co. KG... - Page 27 # Note on stainless steel parts See ‘Cleaning agents for stainless steel’, page 28 User tip ► We recommend Rieber cleaning agent for stainless steel for cleaning stainless steel. ▌ It is an especially thorough yet gentle cleaner, produces a dazzling shine, and cleans and protects in one.
-
Page 28: Cleaning Agents For Stainless Steel
Long-term exposure to sodium hypochlorite can cause damage to the material. It should not be used if possible. Products should be used, which are specified in the list of the German Society of Hygiene and Microbiology (DHGM). Rieber GmbH & Co. KG... -
Page 29: Calculation Basis For Intervals / Overview
Every 6 months Have electrical equipment inspected Page 26 Cold buffet, refrigerator: Remove fluff from the Page 31 ff. condenser Inspect condition of product identification Page 10 Please add your notes here Rieber GmbH & Co. KG... -
Page 30: Hot Buffet
Clean with a hot, mild detergent diluted in water. Rinse with clear water. After cleaning, rub surfaces dry with a soft cloth. ATTENTION Do not clean with vinegar water or acidic liquids, as these could cause damage. Rieber GmbH & Co. KG... -
Page 31: Cold Buffet
Remove appliances and accessories. Observe the instructions in the operating manual provided. ® See ‘varithek 2.0’ operating instructions from Rieber Cold buffet Risk of fire Risk of fire from ventilation grille and machine compartment clogged with fluff. ►... -
Page 32: Refrigerator
Keep the refrigerator of the rolling buffet clean as you would a normal refrigerator. ‘Choose the correct cleaning method’, page 26 Warming cabinet WARNING Risk of burns. Allow the warming cabinet to cool down sufficiently first of all. ‘Choose the correct cleaning method’, page 26 Rieber GmbH & Co. KG... -
Page 33: Troubleshooting
Disconnect the electrical power plug on the appliance before starting repair work. ► Have all electrical repairs carried out by an authorised electrician. Any repairs during warranty period may only be carried out by the Rieber service department. Please contact the Rieber service department. Fault... -
Page 34: Disposing Of Your Product
IMPORTANT Customer service needs information about the type and number of your appliance. If you have a fault which you cannot remedy yourself, please get in touch with your Rieber specialist dealer or the manufacturer's customer service. 10.2 Disposing of your product Your appliance is made of high-quality material which can be reused / recycled. -
Page 35: Warranty And Liability
do not use original spare parts. The "Sales and delivery terms and conditions" of Rieber GmbH & Co. KG shall apply for all warranty claims made against the manufacturer. For instance, any repairs and/or overhaul during the warranty period may only be performed by the manufacturer's service department of Rieber, failing which any claims hereof may be voided. -
Page 36: Contact Address
Contact address Contact address Manufacturer: Responsible for Sales and Service: Rieber GmbH & Co. KG Rieber GmbH & Co. KG Hoffmannstraße 44 Hoffmannstraße 44 D72770 Reutlingen, Germany D72770 Reutlingen, Germany Phone +49 (0) 7121 518-0 Phone +49 (0) 7121 518-170...
