1.2 CREST X-Light V2
Specifications
Confocal scanner
Disk scan rate
Pinhole diameter
Spectral transmission
Z- resolution
Illumination source
Internal excitation changer
Internal dichroic changer
Internal emission changer
Operation mode
Observation
Microscope Compatibility
Control
Software
Size
Sound noise
Working Temperature
Storage Temperature
Weight
Power
graphic symbols:
Not dispersion this product in the environment in accordance to RAEE directive 2003/118CE
Attention
Confocal Imager
Nipkow spinning Disk (pinholes) with single
and double hole pattern
> 2000 scans per second
60 micron single pattern standard, 40-70
micron double pattern standard, custom pattern
on request
360 nm – 700 nm
0.7 micron (PSF); 60X PlanApo 1.4NA
Lumencor LEDs Systems, Laser illumination
System
On request
Automated 5 position wheel (up to 25.5x36 mm
filters).
Automated 8 positions wheel (25mm diameter,
up to 5mm thick filter).
Automated confocal, wide field, bright field,
super-resolution with VCS module add-on
(option)
CCD camera/sCMOS camera port with fixed
position; manual focusing by X-Light V2
focusing hex screw system
Inverted fluorescence microscopes with 100%
camera port. Upright Microscopes
USB serial control
Metamorph, Nis-Elements, MicroManager
11.4 (w)x 14.2 (L) x 9.06 (h) inches
29.00 (w) x 36.00 (L) x 23.00 (h) cm
Background 37db working 45db
15-35 °C
10-70°C
24.3 lbs /11.0Kg
100-240VAC 2.5A 47-63Hz
