1.0 X-Light V2

hardware
TP
1.1 X-Light V2 description
CREST X-Light V2 TP is a high throughput full spectrum spinning disk confocal imager with super-resolution
add-on module capability. It can be attached to all major inverted epi-fluorescence microscopes allowing full
spectrum (360nm-700 nm) confocal imaging.
Detailed Specification:
• Easy plug-in spinning disk box
•
Full compatibility with Crest VCS (Video Confocal Super-resolution) module for 3D resolution enhancement
•
Microscope side-port adapter mounting for original C-mount adapter
• Single hole pattern spinning disk or double hole pattern spinning disk, on same physical disk
- High density hole patterns, with Nipkow design
• Anti Reflection coated spinning disk for highest throughput on the market
• Fast spinning disk 15.000 rpm
• Up to 2000 frame/s (tested with CMOS High Speed Systems)
• Custom hole patterns are available for dedicated applications (90-120 days delivery), from receipt of
customer specification/pattern geometrical description
• Excitation Gimbal mount for easy alignment on custom microscope setup and for best S/N
• LED and Laser excitation mounts for high efficiency coupling
•
Motorized Dichroic five positions Filter Wheel
• Standard eight positions motorized Emission Wheel
•
Extraction tools for easy insertion and removal of both dichroic filter and emission filter
• Up to 22mm field of view for new sCMOS confocal imaging on single hole pattern disk
• Up to 12mm x 12mm field of view in double pattern configuration (for each pattern)
• CCD focal plane easy focusing without moving the CCD Camera
• Adapter for Multimode Laser or SMA-905 fiber excitation
