Rugged Analog Auto-Dial Telephones
Confidentiality Notice .....................................................................................................................1
General Information .......................................................................................................................1
Operation .........................................................................................................................................1
Installation ......................................................................................................................................2
Safety Guidelines ..................................................................................................................................... 2
Security Hardware .................................................................................................................................. 2
Conduit Installation Details ................................................................................................................... 2
Model 227-001 ......................................................................................................................................... 4
Model 247-001 ......................................................................................................................................... 6
Model 257-001 ......................................................................................................................................... 8
Model 277-001 ....................................................................................................................................... 10
Flush-Mount Installation ..................................................................................................................... 10
Surface-Mount Installation using a 236-00x Series or Model 238-001 Enclosure ............................. 11
Models 277-002BH and 277-002BHAC ............................................................................................... 12
Flush-Mount Installation ..................................................................................................................... 12
Surface-Mount Installation using the No. 238-003 Enclosure ............................................................ 13
Programming Auto-Dial Numbers ...................................................................................................... 14
Ringdown Operation ............................................................................................................................ 14
Maintenance ..................................................................................................................................15
Service .................................................................................................................................................... 15
Preventive Maintenance for Models 277-001/-002BH/-002BHAC ................................................... 15
Cleaning .............................................................................................................................................. 15
Prevention ........................................................................................................................................... 15
Volume Control Jumper Setting .......................................................................................................... 16
Auxiliary Output ................................................................................................................................... 16
Replacement Parts and Accessories .............................................................................................17
Specifications ................................................................................................................................18
Electrical (Typical) ................................................................................................................................ 18
Environmental ....................................................................................................................................... 18
Mechanical ............................................................................................................................................. 19
Approvals .......................................................................................................................................20
GAI-TRONICS 3030 KUTZTOWN RD. READING, PA 19605 USA
610-777-1374 ◼ 800-492-1212 ◼ Fax: 610-796-5954
V
ISIT WWW
G A I - T R O N I C S
A H U B B E L L C O M P A N Y
T
A B L E O F
.
-
.
GAI
TRONICS
COM FOR PRODUCT LITERATURE AND MANUALS
®
C
O N T E N T S
Pub. 42004-338K
Advertisement
Table of Contents
Related Manuals for Hubbell GAI-Tronics 227-001
Summary of Contents for Hubbell GAI-Tronics 227-001
-
Page 1: Table Of Contents
Pub. 42004-338K G A I - T R O N I C S ® A H U B B E L L C O M P A N Y Rugged Analog Auto-Dial Telephones A B L E O F O N T E N T S Confidentiality Notice ........................1 General Information ........................1 Operation ............................1... -
Page 2: Confidentiality Notice
Pub. 42004-338K G A I - T R O N I C S ® A H U B B E L L C O M P A N Y Rugged Analog Auto-Dial Telephones Confidentiality Notice This manual is provided solely as an installation, operation, and maintenance guide and contains sensitive business and technical information that is confidential and proprietary to GAI-Tronics. -
Page 3: Installation
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 2 of 21 Installation ATTENTION —Installation should be performed by qualified personnel and only in accordance with the National Electrical Code or applicable local codes. Safety Guidelines When installing any GAI-Tronics telephone equipment, please adhere to the following guidelines to ensure the safety of all personnel: •... - Page 4 Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 3 of 21 Figure 1. Bottom entry conduit installation details (RECOMMENDED for non-metallic enclosures) Figure 2. Top entry conduit installation details (NOT RECOMMENDED) P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-338K.docx 10/19...
-
Page 5: Model 227-001
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 4 of 21 Model 227-001 The mounting and wiring instructions for the Model 227-001 Public Auto-Dial Telephone are as follows: 1. Remove the eight security screws from the front panel. Remove the front panel and set aside. : There is a 7-foot half- modular telephone cord attached to the PCBA in... - Page 6 Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 5 of 21 9. Connect the telephone’s modular cord to the incoming subscriber line with the appropriate connector. 10. Verify operation by calling to and from another telephone. 11. Replace the front panel assembly and tighten the eight front panel screws. Figure 5.
-
Page 7: Model 247-001
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 6 of 21 Model 247-001 1. Remove the four front panel screws using a standard Phillips screwdriver. 2. Remove the front panel assembly and set it aside. 3. Disconnect the 7-foot half-modular telephone cord from the PCBA terminal strip, if connected (see Figure 7). - Page 8 Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 7 of 21 Figure 8. Model 247-001 Mounting Diagram P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-338K.docx 10/19...
-
Page 9: Model 257-001
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 8 of 21 Model 257-001 1. Open the front door and remove the four outermost screws from the mid- section using a standard Phillips screwdriver. 2. Pull the enclosure apart until encountering a slight resistance on the left side. - Page 10 Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 9 of 21 Figure 10. Model 257-001 Mounting Detail P:\Standard IOMs - Current Release\42004 Instr. Manuals\42004-338K.docx 10/19...
-
Page 11: Model 277-001
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 10 of 21 Model 277-001 Flush-Mount Installation Use the supplied back box to mount the Model 277-001 Telephone in a Model 234 Series Communication Station or for flush-mount installations Figure 11. Model 277-001 Outline Drawing 1. -
Page 12: Surface-Mount Installation Using A 236-00X Series Or Model 238-001 Enclosure
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 11 of 21 Figure 12. Model 277-001 Back Box Mounting Detail Surface-Mount Installation using a 236-00x Series or Model 238-001 Enclosure : The back box included with the Model 277-001 Telephone is not required for use with a Model 236 Series or Model 238-001 Surface-Mount Enclosure and must be removed. -
Page 13: Models 277-002Bh And 277-002Bhac
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 12 of 21 Models 277-002BH and 277-002BHAC Flush-Mount Installation : See the cutout and support framing details for installation planning (see Figure 15). 1. Remove the four nuts from the back of the dust cover and remove it from the front panel (see Figure 13 and Figure 14). -
Page 14: Surface-Mount Installation Using The No. 238-003 Enclosure
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 13 of 21 2. Feed the telephone line through either of the cable entry holes in the dust cover (see Figure 14). 3. Connect the telephone’s modular cord to the incoming subscriber line with the appropriate connector. : Telephone line connections directly to TB1 are acceptable. -
Page 15: Programming Auto-Dial Numbers
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 14 of 21 Programming Auto-Dial Numbers 1. Remove the front panel assembly by following the appropriate instructions provided in this manual for your phone. 2. Insert the supplied portable keypad and cable into J7 (see Figure 16). 3. -
Page 16: Maintenance
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 15 of 21 Maintenance Service Contact a GAI-Tronics regional service center for an RA# (return authorization number) if the telephone requires service. Equipment must be shipped prepaid to GAI-Tronics with a return authorization number and a purchase order number. -
Page 17: Volume Control Jumper Setting
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 16 of 21 Volume Control Jumper Setting The handset receiver volume control is factory set to default to its original setting (0 dB) when the telephone is hung up. Move jumper J4 from positions 2 and 3 to positions 1 and 2 to save the current volume control setting when hanging up the telephone (see Figure 17). -
Page 18: Replacement Parts And Accessories
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 17 of 21 Replacement Parts and Accessories Table 1. Replacement Parts Part No. Description ® 10111-104 Handset Assembly with 6-foot Hytrel Coiled Cord, Volume Control, and Noise- Canceling Mic, Black 10117-001 Handset Assembly with 15-inch Armored ... -
Page 19: Specifications
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 18 of 21 Table 2. Available Accessories Part No. Accessories 12565-009 Ring Relay Kit 12565-010 Ring Relay Kit 12573-001 Spring Door Kit 12576-117 Front Panel Replacement Kit 230-001 Pole Mounting Kit, Rugged Phone/RF ... -
Page 20: Mechanical
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 19 of 21 Mechanical Model 227-001 Construction Enclosure ............thick-walled cast aluminum with protective gray coating Panel ......................0.125-inch brushed aluminum Finish ........................gray polyurethane enamel Handset/cord ................G-style with armored cord and volume switch Front panel .................. -
Page 21: Approvals
Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 20 of 21 Approvals Safety of Information Technology Equipment ....UL 60950 and CAN/CSA-C22.2 NO. 60950-00 Enclosures for Electrical Equipment ..............UL 50 TYPE 3R/NEMA 3R FCC Information FCC Registration Number ................US: ADGTE10A-46048HAC Ringer Equivalence Number (REN) .................... - Page 22 Pub. 42004-338K Rugged Analog Auto-Dial Telephones Page 21 of 21 User Instructions (Canada) CP-01, Issue 8, Part I: Section 14.1 NOTICE: The Industry Canada label identifies certified equipment. This certification means that the equipment meets certain telecommunications network protective, operational, and safety requirements as prescribed in the appropriate Terminal Equipment Technical Requirements document (s).
- Page 23 Warranty Equipment. GAI-Tronics warrants for a period of one (1) year from the date of shipment, that any GAI-Tronics equipment supplied hereunder shall be free of defects in material and workmanship, shall comply with the then-current product specifications and product literature, and if applicable, shall be fit for the purpose specified in the agreed-upon quotation or proposal document.
