SenTech STC-MCA5MUSB3 Manual

Usb 3.0 camera
Hide thumbs Also See for STC-MCA5MUSB3:
Table of Contents

Advertisement

Quick Links

Download this manual
STC-MBA5MUSB3
STC-MCA5MUSB3
USB 3.0 Camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC-MCA5MUSB3 and is the answer not in the manual?

Questions and answers

Related Manuals for SenTech STC-MCA5MUSB3

Summary of Contents for SenTech STC-MCA5MUSB3

  • Page 1 STC-MBA5MUSB3 STC-MCA5MUSB3 USB 3.0 Camera...
  • Page 2 STC-MBA5MUSB3/MCA5MUSB3 Safety Precautions For U.S.A. For U.S.A. CAUTION For U.S.A. CAUTION Warning: Warning: CAUTION Warning: RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if DO NOT OPEN RISK OF ELECTRIC SHOCK This equipment generates and uses radio frequency energy and if...
  • Page 3 While every effort has been made to ensure that the details contained in Sentech America’s website and all documentation are correct and up-to-date, Sentech America assumes no liability, legal or otherwise for any errors in listings, specifications, part numbers, process, software or model applications.

  • Page 4: Table Of Contents

    STC-MBA5MUSB3/MCA5MUSB3 Table of Contents I. Notes on PCs with Power Save Mode ........................5 A. Cause of the Issue ................................5 B. Solutions for the Issue..............................5 II. General Specifications ............................6-9 A. Electronic Specifications ..............................6 B. Spectral Response Characteristics ..........................7-8 C.

  • Page 5: Notes On Pcs With Power Save Mode

     The power consumption and the heat of the PC will increase whenever the power save mode is disabled. Please understand and accept this before disabling the power save mode. 2. Disable the power save mode with the Sentech PC power management software (StPowerCtrl) Please refer to the Start-Up Guide for the details.

  • Page 6: General Specifications

    STC-MBA5MUSB3/MCA5MUSB3 General Specifications A. Electronic Specifications Model Number STC-MBA5MUSB3 STC-MCA5MUSB3 1/2.5″5M pixel Monochrome CMOS 1/2.5″5M pixel Color CMOS Image Sensor (Aptina:MT9P031I12STM) (Aptina:MT9P031I12STC) Active Picture Elements 2592(H) x 1944(V) Cell Size 2.2 (H) x 2.2 (V) µm Scanning System Progressive Shutter Type...

  • Page 7: Spectral Response Characteristics

    STC-MBA5MUSB3/MCA5MUSB3 B. Spectral Sensitivity Characteristics 1. STC-MBA5MUSB3 2. STC-MCA5MUSB3 Product Specifications Ver 1.00 For More Information Please Call Aegis Electronic Group, Inc. * (888) 687-6877 Phone * aegis-g2@aegiselect.com * http://www.aegiselect.com...
  • Page 8 STC-MBA5MUSB3/MCA5MUSB3 3. NF-50D (IR Cut Filter) Product Specifications Ver 1.00 For More Information Please Call Aegis Electronic Group, Inc. * (888) 687-6877 Phone * aegis-g2@aegiselect.com * http://www.aegiselect.com...

  • Page 9: Mechanical Specifications

    Approximately 38 g Interface Connectors USB Connector: USB3.0 MicroB type I/O Connector: HR10A-7R-6PB (Hirose) or equivalent D. Environmental Specifications Model Number STC-MBA5MUSB3 / STC-MCA5MUSB3 0 ～ +40℃ Operational Temperature -30 ～+65℃ Storage Temperature Vibration 20Hz to 200Hz to 20Hz (5min./cycle), acceleration 10G, 3 directions 30 min. each...

  • Page 10: Interface Connector Specifications

    STC-MBA5MUSB3/MCA5MUSB3 III. Interface Connector Specifications I/O Connector USB Connector A. USB Connector USB 3.0 Micro-B Type B. I/O Connector  HR10A-7R-6PB (Hirose) or equivalent  This connector is for input triggers and output signals.  Use HR10A-7P-6S (Hirose) or equivalent for the cable side. ...

  • Page 11: Input / Output Specifications

    STC-MBA5MUSB3/MCA5MUSB3 IV. Input / Output Signal Specifications A. Input Signals 1. Input Signal Functions Using the software, the following functions can be set on “Input 1” and “Input 2” of the I/O connector. The polarity of Trigger Input and Sub-Trigger Input is selectable. Function No.
  • Page 12 STC-MBA5MUSB3/MCA5MUSB3 3. Input Signal Circuit 4. Input Signal Circuit Examples CAMERA internal power is applied MAX _5V S N74 LV C2G24 1YZPR (T I) 10 0 o hm INP UT USE R INP UT 10 k oh m IO_GND CUS 03 (Tos hi ba) IO_GND CAMERA MAX _5V...

  • Page 13: Output Signals

    STC-MBA5MUSB3/MCA5MUSB3 B. Output Signals 1. Output Signal Functions  Using the software, the following functions can be set on “Output 1” and “Output 2” of the I/O connector.  The polarity of Trigger Output Programmable, Trigger Output Loop Through, Exposure End, CCD Read End Output, Strobe Output Programmable, Strobe Output Exposure and Trigger Valid Out is selectable.
  • Page 14 STC-MBA5MUSB3/MCA5MUSB3 9). Trigger Valid Out With the positive polarity setting, high status indicates that the input trigger signal is acceptable. This signal becomes low from the exposure start to the end of image output. With the negative polarity setting, low status indicates that the input trigger signal is acceptable. This signal becomes high from the exposure start to the end of image output.
  • Page 15 STC-MBA5MUSB3/MCA5MUSB3 2. Output Signal Electronic Characteristics  Output Signal / Voltage Level High Level: Power Input of the I/O Connector (+3 ~ + 26.4 V) Low Level: Smaller than 0.8 V  Output Signal / Pulse Width Pulse width is settable using the software. Please refer to the response timing chart below and set with a sufficient margin.
  • Page 16 STC-MBA5MUSB3/MCA5MUSB3 3. Output Signal Circuit 4. Output Signal Circuit Examples CAMERA IO_ VCC 22 k oh m USE R OUT PUT 10 0 o hm OUT PUT DTC144 EM (Rohm) CUS 03 (Tos hi ba) IO_ GND *The voltage applied on the “IO_VCC” must be within the range of +3V to 26.4V. Product Specifications Ver 1.00 For More Information Please Call...
  • Page 17 STC-MBA5MUSB3/MCA5MUSB3 USE R_ VCC CAMERA USE R OUT PUT IO_VCC 22 k oh m 10 0 o hm USER_Ic OUT PUT DTC144 EM (Rohm) CUS 03 (Tos hi ba) IO_GND USE R_ GND * When no voltage is applied on “IO_VCC”, it can be used as an open collector output. * The voltage applied on “IO2”...

  • Page 18: Dimensions

    STC-MBA5MUSB3/MCA5MUSB3 V. Dimensions Unit: mm *How to Identify Monochrome and Color Camera. STC-MBA5MUSB3 STC-MCA5MUSB3 Product Specifications Ver 1.00 For More Information Please Call Aegis Electronic Group, Inc. * (888) 687-6877 Phone * aegis-g2@aegiselect.com * http://www.aegiselect.com...
  • Page 19 STC-MBA5MUSB3/MCA5MUSB3 Revisions Date Changes Note April, 5 2012 New document April 12, 2012 Corrected Maximum Frame Rate for VGA April 20, 2012 Added Interface Connector Specifications 1.00 October 25, 2012 Full Release Document Product Specifications Ver 1.00...
