Johnson Controls IOM3731-0A Installation Instructions Manual page 3

Table 1: IOM3731 Feature Callouts and Descriptions
Callout Physical Feature: Description and References
1 Binary Outputs (BOs) Terminal Block. (See
2 Mounting Clip (Three Total) (See
3 Device Address DIP Switch Block (See
4 24 VAC, Class 2 Supply Power Terminal Block (See
5 Cover Lift Tab (One of Two) (See
6 Sensor Actuator (SA) Bus or Field Controller (FC) Bus Terminal Block (See
7 Binary Inputs (BIs) Terminal Block (See
8 LED Status Indicators (See
9 Sensor Actuator (SA) Bus or Field Controller (FC) Bus Port (RJ-12 6-pin Modular Jack) (See
IOM3731-0A Input/Output Module Installation Instructions
Figure 3: IOM3731-0A Physical Features
Table 2)
Figure 3)
Setting the Device
Removing the Controller
Table 2)
Table 6)
Addresses)
Supply Power Terminal Block)
Cover)
SA/FC Bus Terminal Block)
SA/FC Bus Port)
3
