This bitmapped sublocation allows any programmable output to be
cleared (set low) on disarming.
Hold down the [MODE] key and press [3] and [*] i.e [MODE] + [3] +
[*]. The output/s to be cleared will be displayed by illuminated zone
LEDís representing the output i.e. zone 1 = output 1 etc. To toggle the
status of the output, press the [NUMBER OF OUTPUT] + [*] if the
LED were extinguished it will now illuminate and visa versa. To exit
this mode press [#].
L
E
D
1
2
3
4
5
6
7
8
9
1
0
1
1
1
2
1
8
6 .
8 .
U
s
r e
O
t p
L
o
c
t a
o i
n
s
1
3
6
-
1
The IDS1632 provides for 250 user codes. These locations allow the
installer to configure the user code properties.
When the panel is defaulted, User Code 1 defaults to 1234 and is a
Master User Code. All other User Codes are disabled.
IDS1632 INSTALLER MANUAL NO. 700-256-02C ISSUED JUNE 2005 VER 1.01
