IDS1632 INSTALLER MANUAL
NOTES ON DUAL REPORTING
When dual reporting is enabled it is possible to select two different
formats. In this instance all data will be transmitted to each phone
number (i.e. reported twice) utilizing a different format per phone
number.
NOTES ON CONTACT I.D.
If the panel has been programmed to use the Contact I.D format it will
not be necessary to program individual reporting codes. Provision is
made to enable/disable the reporting of certain groups of codes. See
location 118 to120. Table 11 contains a list of standard (default)
Contact I.D reporting codes. Any event that relates to a specific zone,
or to a specific user, will have the relevant zone/user number appended
to the end of the Contact I.D reporting code.
