Installation Instructions
!
IMPORTANT
• DISCONNECT ELECTRICAL SUPPLY BEFORE INSTALLATION OR SERVICING.
• THIS PRODUCT MUST BE EARTHED.
• THIS PRODUCT IS DESIGNED TO OPERATE OUTDOORS. IF REQUIRED TO BE
USED INDOORS PLEASE CONSULT DW WINDSOR.
Product Details
The Kirium Pro range is supplied with entry detached from the lantern.
Dimensions (mm)
A
B
Kirium Pro Midi
451
119
*Maximum weight of lantern including post top entry.
Power Ranges (Watts)
Standard
Kirium Pro Midi
17-79
Column Engagement
The information shown below details the length of column engagement for
each entry option.
Entry Options
76mm Post Top Entry
42mm Side Entry
60mm Post Top and Side Entry
42mm Side Entry
76mm Post Top
Ø42mm
80mm
60mm Post Top and Side Entry
Ø76mm
Ø60mm
Fig. 2 -
Length of column engagement for each entry option.
NOTE!
• Blue Light Retinal Hazard Risk Group 1.
• Exposure Hazard Value (EHV) 1.61.
• Blue Light Hazard Group 0 At A Distance (HD) Of 1.9m From Product.
• Do Not Stare At The Light Source.
• Personnel To Wear Protective Safety Glasses Compliant With 'EN166
1F/EN169' When Commissioning/Maintaining This Product.
Max. Weight (kg)*
Windage m
C
227
5.04
CLO Enabled
15-71
Column Engagement (L)
80mm
110mm
100mm
110mm
100mm
IP66 IK08
2
0.026
Fig. 1 - Kirium Pro Midi
Fasteners Supplied
• 2x M10 Screw
• 4x Disc Spring Washer
• 2x M10 Grub Screw
Tools Required
Tools not supplied.
1
6mm Allen Key
Fig. 3 - Tools required for Kirium Pro Midi installation. Not supplied
Recommended Torque
Entry Mounting Torque (Nm)
Kirium Pro Midi
Fig. 2
Kirium® Pro is a registered design
Due to continuous product development the details within this document are subject to change at any
time, please contact us for the most up-to-date information or visit: www.dwwindsor.com
DW Windsor
Pindar Road, Hoddesdon, Hertfordshire, EN11 ODX
T: +44 (0) 1992 474600 | E: info@dwwindsor.com
www.dwwindsor.com
Sheet 1 of 4
The Kirium Pro Range
230VAC 50Hz
B
A
2
5mm Allen Key
Column Mounting Torque (Nm)
36
LED Road Light
Kirium Pro Midi
C
Fig. 1
3
Slotted Screwdriver
Fig. 3
16
