Installation Instructions
IMPORTANT
• DISCONNECT ELECTRICAL SUPPLY BEFORE INSTALLATION OR SERVICING.
• THIS PRODUCT MUST BE EARTHED.
• THIS PRODUCT IS DESIGNED TO OPERATE OUTDOORS. IF REQUIRED TO BE
USED INDOORS PLEASE CONSULT DW WINDSOR.
• DO NOT LOOK DIRECTLY AT LED LIGHT SOURCE
• THE LUMINAIRE SHOULD BE POSITIONED SO THAT PROLONGED STARING
INTO THE LUMINAIRE AT DISTANCE CLOSER THAN X M IS PREVENTED
PRODUCT DETAILS
CxS
kg (PP cover)
kg (AL cover)
C
B
KIRIUM ECO MINI
A
588mm
B
180mm
C
0.029m
587.8
587.8
A
IP66 IK08
KIRIUM ECO MIDI
135mm
2
3.8
4.3
Kirium ECO
588mm
180mm
135mm
587.7
0.030m
2
587.7
4.1
4.6
230VAC 50Hz
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for DW Windsor KIRIUM ECO Series
Summary of Contents for DW Windsor KIRIUM ECO Series
- Page 1 • THIS PRODUCT MUST BE EARTHED. 230VAC 50Hz • THIS PRODUCT IS DESIGNED TO OPERATE OUTDOORS. IF REQUIRED TO BE USED INDOORS PLEASE CONSULT DW WINDSOR. • DO NOT LOOK DIRECTLY AT LED LIGHT SOURCE • THE LUMINAIRE SHOULD BE POSITIONED SO THAT PROLONGED STARING...
- Page 2 POST TOP SIDE ENTRY REMOVE GRUB SCREWS AND NUTS, REVERSE AND RE-INSERT SO THAT DRIVE HEX IS EXTERNAL REVERSE SEQUENCE IF SWITCH FROM SIDE ENTRY TO POST TOP...
- Page 3 TILT ADJUSTMENT +1Nm 16Nm LOOSEN THE BOLTS UNTIL TILTING IS POSSIBLE DO NOT OVER LOOSEN RETIGHTEN TO REQUIRED TORQUE SIDE ENTRY 10° 7.5° 5° 2.5° 0° -2.5° -5° -7.5° -10° POST TOP 15° 12.5° 10° 7.5° 5° 2.5° 0° -2.5° -5°...
- Page 4 Philips Head Screwdriver. Tighten gland cap to 6Nm to ensure IP sealing is maintained. DW Windsor Due to continuous product development the details within this document Pindar Road, Hoddesdon, Hertfordshire, EN11 ODX are subject to change at any time, please contact us for the most up-to-date T: +44 (0) 1992 474600 | E: info@dwwindsor.com...
