Precision cut-off machine – Struers Minitom
User instructions
Operation of this equipment is restricted to trained personnel familiar with the user
instructions, general safety precautions, and laboratory rules. Contact the laboratory
manager or your supervisor/group leader to get permission to use this equipment.
Specimen holder arm
Adjustable stop plate/
Micrometer screw and
lock for micrometer
screw
Adjustable knob for
setting the required
speed for the cut-off
wheel.
Always Use Personal Protective Equipment
Safety glasses
must be worn.
START button
STOP button
Working gloves
must be worn.
Front weight
Sample holder
Rear weight
Splash guard
Cut-off wheel
Shutter for cooling
tank
Rings and jewelry
must not be worn.
Updated 14.10.2019
Nélia Castro
Advertisement
Related Manuals for Struers Minitom
Summary of Contents for Struers Minitom
- Page 1 Precision cut-off machine – Struers Minitom User instructions Operation of this equipment is restricted to trained personnel familiar with the user instructions, general safety precautions, and laboratory rules. Contact the laboratory manager or your supervisor/group leader to get permission to use this equipment.
- Page 2 The specimen must protrude at least 6 mm from the specimen holder. 2. Adjust the stop plate up or down so that Minitom stops when the specimen has been cut throught: a) Turn the lock on the micrometer screw counter clockwise.
