Transmitter; Battery Charging - XciteRC X-Dive micro U-Boot yellow Manual

• WARNING: check the transmitter LED also during operation. If the LED stops lighting up when
pushing a button, stop operation, switch the model off and replace the transmitter batteries – crash
EN
hazard!

Transmitter

Move forward
Move backward

Battery charging

WARNING: Be sure to read all safety instructions regarding the use of rechargeable batteries. Charging
may take place only with the supplied charger on a fireproof surface and under constant adult supervision -
fire or explosion hazard!
USB connector
• Insert the charger into an USB socket of your PC.
• Connect the charging wire to the U-Boot (see picture).
• WARNING: the charging cable is polarized, pay attention to the guide rail in the connector housing.
The plug must snap into place relatively easily, do not use force - fire or explosion hazard!
• During charging, the red LED on the charger lits. A fully discharged battery takes about 30 minutes until
it is fully charged - the red LED goes out.
• Unplug the battery from the charger.
• Unplug the charger from the socket when you no longer need it.
The run time of the X-Dive micro U-Boot is about 20 minutes.
16
Turn left
Turn right
Push to go up
Push to dive
Charging plug
Socket
Transmitter · Battery charging
Position Pin
insert
X-Dive micro U-Boot
