  • Page 1 Bedienungsanleitung Manual Mode d‘emploi #12006000 XciteRC Flybar 180S Coax IR red #12006000 XciteRC Flybar 180S Coax IR red #12006000 XciteRC Flybar 180S Coax IR red #12006000 XciteRC Flybar 180S Coax IR red #12006000 XciteRC Flybar 180S Coax IR red #12006000 XciteRC Flybar 180S Coax IR red...
  • Page 2: Table Of Contents

    Ausstattung vorbehalten. Aus Angaben und Abbildungen dieser Bedienungsanleitung können keine Ansprüche abgeleitet werden. KEINE HAFTUNG FÜR DRUCKFEHLER! ÄNDERUNGEN VORBEHALTEN! Die jeweils neueste Version dieser Anleitung finden Sie im Internet unter www.XciteRC.de © Copyright 2013 by XciteRC-Modellbau GmbH & Co. KG XciteRC Flybar 180S Coax...
  • Page 3: Bestimmungsgemäße Verwendung

    Einführung Vielen Dank für den Kauf des FLYBAR 180S Coax von XciteRC. Die vorliegende Bedienungsanleitung ent- hält wichtige Hinweise für den Betrieb Ihres neuen Modells. Lesen Sie deshalb, bevor Sie das Modell in Betrieb nehmen, alle Anweisungen dieser Bedienungsanleitung vollständig durch, damit Sie Ihr Modell gefahrlos betreiben können.
  • Page 4 Sicherheitshinweise schäden, die durch unsachgemäße Handhabung oder Nichtbeachtung der Sicherheitshinweise entstehen, übernimmt die XciteRC Modellbau GmbH & Co. KG keine Haftung. In diesen Fällen erlischt die Gewährleis- tung. Bewegen Sie Ihr Modell immer mit größter Vorsicht und Verantwortung, ansonsten kann es zu Schäden an fremden Eigentum oder gar Personenschäden kommen.
  • Page 5: Sicherheitshinweise Zum Umgang Mit Batterien Bzw. Akkus

    Lithium-Akku längere Zeit gelagert, kann er beschädigt werden. Die Firma XciteRC Modellbau GmbH & Co. KG kann den korrekten Umgang mit den von Ihnen verwendeten Akkus bzw. Batterien nicht überwachen, daher wird die Gewährleistung bei falscher Ladung oder Entladung ausgeschlossen.
  • Page 6: Das Fernsteuersystem

    Fernsteuersystem Das Fernsteuersystem Im Folgenden bekommen Sie einen Überblick über das Fernsteuersystem Ihres XciteRC FLYBAR 180S Coax und über seine verschiedenen Funktionen und Einstellungen. Vor dem ersten Flug sollten Sie unbedingt alle diese Funktionen und Einstellungen gelesen und verstanden haben.
  • Page 7: Akku Aufladen

    WARNUNG: Nur mit ausreichend vollen Senderbatterien und vollständig geladenem Flugakku star- ten – Absturzgefahr! • Überprüfen Sie alle Teile des XciteRC FLYBAR 180S Coax auf Beschädigungen sowie Schmutz. Tauschen Sie beschädigte Teile aus und reinigen das Modell, da Schmutz das Gewicht erhöht und damit die Flug- eigenschaften verschlechtern kann.
  • Page 8: Rc-Funktionen

    Nase nicht mehr bewegt. Dreht er sich nach rechts, Trimmhebel nach links drücken. Landen: • Ziehen Sie den linken Gashebel vorsichtig nach hinten, der Helikopter sinkt. Versuchen Sie, möglichst „weich“ zu landen um das Modell zu schonen. XciteRC Flybar 180S Coax...
  • Page 9: Wartung

    • Nach der Landung Modell und anschließend Sender ausschalten. WARNUNG: der Motor des XciteRC FLYBAR 180S Coax wird während des Betriebs sehr warm. Lassen Sie ihn vor dem nächsten Start mindestens 20 Minuten abkühlen, um ihn nicht zu beschädigen -...
  • Page 10: Hinweise Zum Umweltschutz

    Sie es - bevor Sie es benutzt haben - an Ihren Fachhändler oder an uns zurück und wir werden Ihnen Ersatz liefern. Für den XciteRC FLYBAR 180S Coax sind einige Teile als Ersatzteile verfügbar. Ist ein Teil defekt oder ver- schlissen, können Sie es mit Hilfe der Explosionszeichnungen identifizieren und neu erwerben.
  • Page 11 Diese durchgekreuzte Mülltonne bedeutet, dass Sie Batterien und Akkus nicht im Hausmüll entsorgen dür- fen. Unter diesen Zeichen finden Sie zusätzlich nachstehende Symbole mit folgender Bedeutung: • Cd = Cadmium • Pb = Blei • Hg = Quecksilber • Li = Lithium Li-Po XciteRC Flybar 180S Coax...
  • Page 12 Text and illustrations of this manual, no claims can be derived. NO LIABILITY FOR PRINTING ERROR! SUBJECT TO CHANGE! The latest version of this manual can be found on the Internet at www.XciteRC.de © Copyright 2013 by XciteRC-Modellbau GmbH & Co. KG...
  • Page 13: Intended Usage

    All company and product names mentioned are trademarks of their respective owners. All rights reserved. Intended Usage The Flybar 180S is an electrically driven ready to run helicopter including motor and speed controller. The control is wireless with the included infrared remote control. The model may only be operated on a suitable and sufficiently large room without direct sunlight and obstacles.
  • Page 14 WARNING: remove the drive battery from the model and transmitter after use. Store the model never with built-in battery. Fire hazard! • Store batteries separately on a non-combustible surface. • The drive components (motor and speed controller) or the car battery may become hot during operation. XciteRC Flybar 180S Coax...
  • Page 15: Handling Precautions For Batteries Or Rechargeable Batteries

    The XciteRC Modellbau GmbH & Co. KG cannot monitor the proper use of the battery or batteries you use, therefore, the warranty is excluded due to incorrect charging or discharging.
  • Page 16: The Remote Control System

    The remote control system Here you get an overview of the remote control system of your XciteRC Flybar 180S and its various features and settings. Before the fi rst fl ight, you should absolutely have read and understood all these functions and settings.
  • Page 17: Battery Charging

    • Check the motor and servo functions. • If the fl ight battery runs low, the motor speed is reduced and the helicopter sinks automatically. Find a suitable place to land safely. Charge the fl ight battery again. XciteRC Flybar 180S Coax...
  • Page 18: Rc Functions

    NOTE: if the fl ight battery runs empty, the helicopter does not respond accurately to your com- mands, the fl ight is unstable. In this case land immediately. • Switch of the helicopter and then the transmitter. XciteRC Flybar 180S Coax...
  • Page 19: Maintenance

    – to your dealer or directly to us and we will send you a replacement. For the Flybar 180S some parts are available as spares. If a part is defective or worn, you can identify it with the help of the exploded view.
  • Page 20: Environmental Protection Notes

    Environmental Protection 40 799 50 Email: service@xciterc.de Spare parts for the XciteRC FLYBAR 180S you may order in your local hobby shop or online at http://www. XciteRC.de/ Environmental Protection Notes The symbol of the crossed out dust bin on the product or packaging indicates that this product must be disposed of separately from normal household waste.
  • Page 21 XciteRC Flybar 180S Coax...
  • Page 22 NOUS DECLINONS TOUTE RESPONSABILITE EN CAS D ERREUR D’ IMPRESSION! NOUS NOUS RESERVONS LE DROIT DE MODIFICATION! Veuillez trouver la dernière version de cette notice d’emploi dans l’internet sous www.XciteRC.de © Copyright 2013 by XciteRC-Modellbau GmbH & Co. KG XciteRC Flybar 180S Coax...
  • Page 23: Utilisation Destinée

    Conservez le pour votre lecture mais aussi remettez cette documentation à tierce person- ne si vous décidez de prêter ou vendre le Flybar 180S. Notre garantie ne couvrira aucun dégât ou mauvais fonctionnement en cas de non-respect du mode d’emploi et des consignes de sécurité.
  • Page 24 Il est impératif de stopper l’utilisation pour recharger les accu- mulateurs. • Respectez soigneusement les consignes et les avertissements contenus dans ce mode d’emploi du Flybar 180S, ainsi que ceux de tous les accessoires que vous utiliserez en accompagnement de celui-ci (chargeurs, accumulateurs rechargeables etc.). •...
  • Page 25 , sera endommagé. La société XciteRC Modelbau GmbH & Co.KG ne peut pas contrôler la manipulation des accus faite par l’utilisateur et de ce fait, ne peut pas être tenue responsable d’une mauvaise opération de chargement ou...
  • Page 26: La Télécommande

    LED sur la platine située clignote 3 x, tous les En fréquence A la LED réglages sont réinitialisés. POWER clignote 1x, dans le fuselage s’allume, appuyez une nouvelle fois pour la fréquence B, vous pouvez voler. la LED clignotera 2x. XciteRC Flybar 180S Coax...
  • Page 27: Chargez L'accu

    Perte de contrôle! • Vérifi ez toutes les pièces du Flybar 180S, il ne faut pas qu’elles soient endommagées ou sales. Rempla- cez les pièces défectueuses et nettoyez le modèle, la saleté, qui augmente le poids du modèle, entrave les caractéristiques de la navigation.
  • Page 28: Fonctions Rc

    • Ramenez avec la plus grande prudence le manche gauche de commande des gaz vers l’arrière, l’hélicoptère perd de l’altitude. Essayez de vous poser en douceur pour ménager le modèle. • A NOTER: si l’accu de vol arrive en fi n de charge, les réactions de l’hélicoptère aux ordres de com- XciteRC Flybar 180S Coax...
  • Page 29: Entretien

    état de marche et ne s’use qu’avec modération. • L’ Flybar 180S est étanche, il se peut néanmoins que quelques gouttes d’eau s’infiltrent dans le bateau. C’est pourquoi, après chaque séance, vérifiez si de l’eau s’est accumulée au fond de la coque, si c’est le cas, asséchez avec un chiffon.
  • Page 30: Consignes Pour La Protection De L'environnement

    – avant la première mise en route – retournez le modèle sans attendre à votre concessionnaire ou directe- ment chez nous afin que nous procédions à un échange. Toutes les pièces du Flybar 180S peuvent être disponibles comme pièces détachées. En cas de pièces défectueuses, vous pouvez vous aider du dessin éclaté pour l’identifier et la commander.
  • Page 31 Le symbole de la poubelle barrée signifie que les piles et les accumulateurs ne doivent pas être jetés dans la poubelle classique. Ci-dessous les symboles que vous reconnaitrez • Cd = Cadmium • Pb = Plomb • Hg = mercure • Li = Lithium Li-Po XciteRC Flybar 180S Coax...
  • Page 32 Reparaturset Rotorkopf Rotorblätter Flybar 180S Landegestell Rotor Head Repair Set Main Blades Flybar 180S Landing Gear Set de pièces de réchange pour tête de Pales de rotor Flybar 180S Train d'atterissage rotor 12006005 12006006 12006004 USB-Ladekabel runder Stecker Sender IR Flybar 180S Hauptzahnräder und Wellen...
  • Page 33: Konformitätserklärung

    XciteRC Flybar 180S Coax...
  • Page 34 XciteRC Flybar 180S Coax...
  • Page 35 XciteRC Flybar 180S Coax...
  • Page 36 XciteRC Modellbau GmbH & Co. KG Autenbachstraße 12 D-73035 Göppingen Phone: +49 7161 40 799 0 Fax: +49 7161 40 799 99 E-Mail: info@xciterc.de Web: www.XciteRC.de...
