Lancom AirLancer IN-Q180 Mounting Instructions page 5

Technical details
Frequency range
Antenna characteristics
Radiation characteristics
Recommended use
VSWR
Gain
Mechanical details
Size
Weight
Temperature range
Color
Material
Mounting options
Cables, connectors
Item
Warranty
Item number
Package content
Antenna patterns
2.4 GHz
5 GHz
2400 - 2500 MHz (red marked connectors),
4900 - 5900 MHz (white marked connectors)
horizontal (2.4 GHz)
vertical (2.4 GHz)
horizontal (5 GHz)
vertical (5 GHz)
Room coverage
1.5:1 typ. / 2.5:1 max.
2.4 GHz 3 dBi max.
5 GHz 5 dBi max.
130 x 130 x 45 mm (length x width x height)
208 g (antenna without mounting kit)
-20 °C to 65 °C
White
UV-resistant plastic
Ceiling- and wall mounting
4 x 1 m RG178 cable with RPSMA plug
2 years for AirLancer and accessories
61249
Antenna, fastening material for ceiling- and wall mounting, mounting
instructions
360°
55°
220°
40°
