  • Page 1 RADA AIR TIGHT C PELLET STOVE EN Installation, use and maintenance page 2...

  • Page 2: Table Of Contents

    RADA AIR TIGHT C Performance declaration (DoP - EK n° 177) Moreover, the company hereby declares that: the RADA AIR TIGHT C wood pellet stoves satisfy the requirements of the following European directives: 2014/35/EC - Low Voltage Directive 2014/30/EC - Electromagnetic Compatibility Directive...

  • Page 3: Introduction And Readers Of This Manual

    European regulations. For the First ignition is required for activation of the Edilkamin installation, and for anything not specifically indicated in the manufacturer warranty. The warranty is only valid in the manual, observe local regulations.

  • Page 4: Safety Information

    • Blocking the aeration vents and air refer to the warranty certificate inside the intakes in the room. DO NOT BLOCK product: specifically, neither Edilkamin nor THE AERATION VENTS OR FLUE. Risk the retailer are liable for damage resulting of smoke returning into the room with from incorrect installation or maintenance.

  • Page 5: Dimensions

    DIMENSIONS RADA AIR TIGHT C - DIMENSIONS (cm) Ø 6 Ø 6 cm ducting ducting (optional) 15 12,5 Ø 8 cm smoke outlet Ø 13 cm coaxial USER/INSTALLER...

  • Page 6: Technical Data

    Stand by absorption Power Absorbed power on ignition 365 W Remote control frequency (provided) 2,4 GHz Protection rating Fuse 4 AT, 250 Vac 5x20 EDILKAMIN s.p.a. Reserves the right to modify the product without notification in the inte- rests of improvement. USER/INSTALLER...

  • Page 7: Unpacking

    UNPACKING UNPACKING AND PREPARATION Packing employed materials are not toxic or harmful and do not require specific disposal. Storage, disposal or possible recycling must be provided by the user in compliance with relative applicable laws. Each handling operation must be performed in vertical position by appropriate means and in accordance with current safety regulations.
  • Page 8 UNPACKING DO NOT REMOVE THE PRODUCT FROM THE PALLET BEFORE OPENING THE DOOR AND LOOSENING THE SCREWS. HOW TO REMOVE THE STOVE FROM THE PALLET 1. Remove the sides loosening the upper screws 2. Open the door and remove the fan protection grid 3.

  • Page 9: Installation

    Remember that Rada Air Tight C is sealed, in other Contact the retailer for this type of optional. words, if it is installed correctly with the air inlet pipe...
  • Page 10 INSTALLATION INSTRUCTIONS SMOKE THE FUMES DUCT DISCHARGE WITH WITHOUT • Further to the general prescriptions for the fumes CONCENTRIC PIPE duct and flue, the fumes duct: • may not be made of flexible metal material • must be insulated, if routed through unheated FLUE SYSTEM areas or outdoors (fumes duct, flue and chimney pot)
  • Page 11 INSTALLATION INTUBATED SYSTEM: Further to the general prescriptions for the fumes duct and flue, the intubated system: • must operate in negative pressure; • must be open to inspection; • must observe local regulations. THE CHIMNEY POT (In every country and specially in France, check on the specific waiver conditions) •...
  • Page 12 INSTALLATION COMBUSTION AIR INTAKE USE OF CONCENTRIC PIPES The inflow of necessary air for combustion, of air for Without prejudice to the general instructions, you can glass cleaning and heating air renewal must come use concentric pipes (which provide for the passage of from the outside smoke inside and the passage of the combustion air into the external circular ring).
  • Page 13 The electrical system must be compliant; check the operation of the earth in particular. Edilkamin is not responsible for malfunctions resulting from an improperly earthed system. The power line must be of adequate section for the power of the appliance.

  • Page 14: Cladding

    CLADDING 1. With sides removed, assemble the two side tiles to the side fixing bracket using supplied screws and washers NOTE Use supplied screws and washers to fix ceramics as shown in sequence. Do not tighten too much to prevent possible inserts breakage.
  • Page 15 CLADDING 2. Fit back the sides inclusive of brackets and ceramics, screwing them on the upper part. Screws to fit the side SETTINGS Align the upper ceramic edge with the top one. 3. Open the sliding lid fitting the front tile with supplied screws and washers.
  • Page 16 CLADDING 4. Loosen the screws holding the tank lid hinge to the body and remove the rear part of the fixed top where product coaxial joint is located. Fit the two remaining tiles using supplied screws and washers. NOTE: Use high temperature silicone to fix the tile well; just apply a layer right in the middle of the tile to fix it to the tinny holder.sufficiente stendere un codone orizzontale nel centro della piastrella per fissarla al supporto metallico.

  • Page 17: Instructions For Use

    USER INSTRUCTIONS FIRST IGNITION (COMMISSIONING) PHASES PELLET LOADING • Make sure you have read and understood this Gently slide the top until the end stop to load pellet. manual Open the inner hatch and just pour pellet making sure • Remove all flammable materials from the appliance not to spill it out (manuals, labels, etc.).
  • Page 18 USER INSTRUCTIONS OPERATION PHASES Further to the above operational procedures, the stove has the following phases Description. The access to and adjustment of these functions is described below: - Ignition Flame ignites and grows stable. Mode Size settings This is the result of: MANUAL •...
  • Page 19 • Open the bottom of the remote the intensity of use. Edilkamin and the retailer control and insert the 2 batteries in will not consider claims for battery life under any the indicated orientation.
  • Page 20 USER INSTRUCTIONS The display reads the POSSIBLE STATES described below: - OFF STATE The product is shutting down or is off in response to a manual switching off by using the ON/OFF button of the remote control or due to an external contact (crono, phone dialler) The display shows the current time, room temperature and the status in relation to which the product is OFF.
  • Page 21 (starts the switch off phase) Letter “A” will appear beside the fan blades icon. manually in Manual mode only. In Automatic mode, the product responds to the Nearest Edilkamin Technical Assistance heating demand. Centre must...
  • Page 22 USER INSTRUCTIONS - Relax function - Stand by Natural convection function (without ventilation) with When the Stand by function is active, in automatic automatic power limiting. and crono modes, the product shuts off when the This function is available in all modes: automatic, temperature setpoint is reached and turns on again manual and crono.
  • Page 23 USER INSTRUCTIONS Crono The following screen will appear. Scroll to “ENABLE” (underlined) using the “+/-” buttons. When the Crono function is active, the user sets a To enable the Crono function to 7 days a week or temperature setpoint and a time zone for which that on single days (“ENABLE”...
  • Page 24 USER INSTRUCTIONS To combine one of the three temperatures To set the temperature setpoints (“TEMP” on to a time period (“SET” on the display), from the the display), from the Crono function, press the “OK” Crono function, press the “OK” button. The following button.
  • Page 25 USER INSTRUCTIONS The second screen (accessible by pressing the “OK” To view/change the settings (“CHANGE” on button from the first screen) allows you to set the start the display), from the Crono function, press the “OK” button. The following screen will appear. and end time of the time period matching the chosen Scroll to “CHANGE”...
  • Page 26 USER INSTRUCTIONS Night (deferred switching on/off) Load Pellets This function switches the product on/off after a set Allows you to load pellets after the screw feeder has emptied following a no-pellets alarm. period from activation of the function. Useful for the technician during commissioning. This is convenient if you go to bed and want the product Available only in the OFF state.
  • Page 27 USER INSTRUCTIONS Date/Time Beep Sets the current date/time. Allows you to enable/disable the beep. This displays the first time the remote control is To access the function from the main menu (as activated with the stove powered on, or by selecting indicated in the Menu section above), press the M the option in the menu.

  • Page 28: Maintenance

    MAINTENANCE Before doing any maintenance, disconnect the appliance from the mains. Regular maintenance is essential to keep the appliance in good working order. Failure to service the product properly will prevent it from working properly. Any problems due to failure to service the stove will void the warranty. DAILY MAINTENANCE These jobs should be done with the product off, cold and preferably disconnected from the mains.
  • Page 29 MAINTENANCE 1. Open the combustion chamber door (P) using the removable handle provided. 2. The burning pot (A) slips into position in its housing. Empty the ash tray(B) and burning pot into a non-flammable container (the ashes may still contain embers and/or hot parts) or vacuum if cold. Vacuum out the interior of the combustion chamber, the bed, and the compartment around the burning pot into which the ash falls.
  • Page 30 For any spare parts, contact your dealer or technician. flue every 3 months. Using non-original spare parts may damage the appliance and relieves Edilkamin of all liability for You should clean the chimney system at least once a damage resulting such use.

  • Page 31: Troubleshooting

    TROUBLESHOOTING If problems occur, the product shuts itself off automatically. The display will show the reason (see below). Do not disconnect from the power supply. To start the appliance up again, allow the shutdown procedure to complete, then press the ON/OFF button on the remote control.
  • Page 32 TROUBLESHOOTING MESSAGE PROBLEM SOLUTION • Check the type of pellet (contact the technician if in Shut-down due to exceeding doubt) maximum fumes temperature. • contact the technician Switching OFF due to excessive • see HO7 overheating of the product. Shut-down due to gearmotor •...
  • Page 33 The battery symbol will appear on the remote control display if the battery is low. MAINTENANCE: A wrench symbol is shown on the display after 2000 hours of operation. The product is working, but it must be serviced by an authorised Edilkamin technician. USER/INSTALLER...
  • Page 36 *942040-GB* w w w . e d i l k a m i n . c o m cod. 942040-GB 07.19/B...
