InTouch Health Xpress Quick Start Manual

Operating the Xpress

Directional Microphone
Touch Screen Display
When someone is logged in,
their video feed and
username is displayed.
Otherwise a screensaver will
be seen on the screen.
Power (ON/OFF)
Connect/
Disconnect
Volume Control
Mute
Hold
Press NETWORK to select from wireless
networks using the touch Screen Display
Power Connector

Installing the Battery and Charging

1. Slide the latch to unlock and open the battery
door as shown.
2. Pull the tab to remove the battery.
3. Install the charged battery with the tab exposed.
4. Slide the latch to close the battery door.
5. Plug the Xpress AC/DC power adapter into a
standard, grounded 120 Volt AC outlet to charge
the device.
NOTE: The Xpress battery can be changed while in
session if the Xpress is connected to an AC power
supply with the InTouch Health provided power
adapter.
Xpress™ Quick Start Guide
24/7 Technical Support (877) 484-9119
Viewfinder
Allow the Xpress to charge initially for at least 5 hours to
reach a full charge. Other than charging the batteries, no user
maintenance of the batteries is required.
The battery can last approximately 3 hours on a full charge.
The Xpress will not run if the battery charge is less than 20%.
The system will charge to 20% from 85% in 4.25 hours.
The system will charge to 20% from 100% in 5 hours.
Camera
Speaker
Tap the screen (out of
sessions) to show status,
battery charge, wireless signal
quality and other information.
