Motorola RMN5127 User Manual

Mobile microphone
Hide thumbs

Advertisement

Quick Links

Mobile Microphone
RMN5127
User Guide
EN
FR
LAS
ES
BP
IT
FRC
PR
NL
ID
RU
DE

Advertisement

loading

  Related Manuals for Motorola RMN5127

  Summary of Contents for Motorola RMN5127

  • Page 1 Mobile Microphone RMN5127 User Guide...
  • Page 3: Acoustic Safety

    FOREWORD This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation.
  • Page 4: Installation

    DESCRIPTION The Mobile Keypad Microphone (Mic), Motorola® Kit Number RMN5127 is a full keypad handheld microphone. The keypad on this microphone is intended to assist in navigating through the menus on its parent device, as well as entering information such as phone numbers and menu picks.
  • Page 5 Vehicle Dashboard HLN9073 Microphone Hang-up Clip MAEPF-26073-O ITEM DESCRIPTION NUMBER Hang-up Clip Flat-Head Screw Hex-Washer Head Screw Back-up Plate Insert button on rear housing of Mic into hang-up clip. Insert the GCAI plug on the radio end of the Mic cord into the GCAI jack on the front of the radio.
  • Page 6: Operation

    Turn the locking collar on the radio end of the mic cord ¼ turn clockwise to secure it in place. DISCONNECTING MIC FROM RADIO Turn the locking collar on the radio end of the mic cord ¼ turn counter clockwise. Pull the cord connector from GCAI connector to release.
  • Page 7 REPLACING MIC CORD Removing Cord from Mic Body Refer to illustration on next page. Grasp locking collar and, while pushing it firmly towards mic body, turn it counterclockwise ¼ turn to disengage it from mic body. Disconnect cord from mic body by pulling TELCO connector (which has no tab on it) out of TELCO jack on circuit board inside mic body.
  • Page 8 TELCO Connector Strain Relief Locking Collar GCAI Connector Tabs...
  • Page 9 FIELD REPLACEABLE UNITS ITEM MOTOROLA DESCRIPTION NUMBER PART NO. 3205508Z02 O-Ring, White (On Mic Head) 3064153H04 Coil Cord Push-to- Talk (PTT) Microphone Button Navigation Keys Home Key Menu Key Back Key OK Key Keypad Buttons Keypad Mic - front view...
  • Page 10 1303 E. Algonquin Rd., Schaumburg, IL 60196 U.S.A. MOTOROLA, MOTO, MOTOROLA SOLUTIONS and the Stylized M logo are trademarks or registered trademarks of Motorola Trademark Holdings, LLC and are used under license. All other trademarks are the property of their respective owners.
