Installation and Operating Manual
Do not operate this equipment unless you have
read and understood the contents of this manual!
Failure to follow the instructions contained in this
manual may result in serious injury or death. This
manual contains important safety information
concerning the maintenance, use, and operation
of this product. If you're unable to understand the
contents of this manual, please bring it to the
attention of your supervisor. Keep this manual in
a safe location for future reference.
GLO-RAY
Mini-Merchandisers
GRHW Series
P/N 07.04.357.00
®
No opere este equipo al menos que haya leído y
comprendido el contenido de este manual!
Cualquier falla en el seguimiento de las
instrucciones contenidas en este manual puede
resultar en un serio lesión o muerte. Este manual
contiene importante información sobre seguridad
concerniente al mantenimiento, uso y operación
de este producto. Si usted no puede entender el
contenido de este manual por favor pregunte a su
supervisor. Almacenar este manual en una
localización segura para la referencia futura.
© 2011 Hatco Corporation
Advertisement
Table of Contents
Related Manuals for Hatco GLO-RAY GRHW Series
Summary of Contents for Hatco GLO-RAY GRHW Series
- Page 1 Keep this manual in supervisor. Almacenar este manual en una a safe location for future reference. localización segura para la referencia futura. © 2011 Hatco Corporation...
-
Page 2: Table Of Contents
Register your unit! Completing online warranty registration will prevent delay in 24 Hour 7 Day Parts and Service obtaining warranty coverage. access the Hatco website at Assistance available in the United States www.hatcocorp.com, select the Parts & Service pull-down and Canada by calling (800) 558-0607. -
Page 3: Important Safety Information
This unit has no “user-serviceable” parts. If service is • Turn OFF power switch, unplug power cord, and allow required on this unit, contact an Authorized Hatco Service unit to cool before performing any maintenance or Agent or contact the Hatco Service Department at cleaning. -
Page 4: Model Description
MODEL DESCRIPTION GRHW-1SGD and GRHW-1SGDS Models All Models The GRHW-1SGD and GRHW-1SDS models feature a GRHW Series mini-merchandisers use a limited amount of stainless steel or hardcoated heated base and an upper heated counterspace and come in a variety of shapes, sizes, and colors glass shelf with glass side panels. -
Page 5: Model Designation
NOTE: The specification label is located on the top rear of the unit. See label for serial number and verification of unit Figure 5. Plug Configurations electrical information. NOTE: Receptacle not supplied by Hatco. Electrical Rating Chart Model Voltage Watts... -
Page 6: Dimensions
SPECIFICATIONS Dimensions Model Width Depth Height Footprint Footprint Width (D) Depth (E) GRHW-1P 22-1/4″ 19-1/8″ 17-3/4″† 19-7/8″ 11-3/8″ (565 mm) (486 mm) (451 mm) (505 mm) (289 mm) GRHW-2P 43-1/4″ 19-1/8″ 20-3/4″ 40-7/8″ 11-3/8″ (1099 mm) (486 mm) (527 mm) (1038 mm) (289 mm) GRHW-1SG... -
Page 7: Installation
INSTALLATION General 6. Place the unit in the desired location. Two people are required for this step. Glo-Ray GRHW Series mini-merchandisers are shipped with ® • Locate the unit in an area where the ambient air most components pre-assembled. Care should be taken when temperature is constant and a minimum of 70°F (21°C). -
Page 8: Installing The Sneeze Guard
INSTALLATION GRHW-1SGD and GRHW-1SGDS Models 2. Secure the side panel to the support posts using the four supplied screws. Do not over-tighten the screws. 1. align the four holes in the sneeze guard and support trim with the four studs located underneath the front top of the unit. 2. -
Page 9: Operation
OPERATION General GRHW-1SGD and GRHW-1SGDS 1. move the Power On/Off switch to the “On” position. Use the following procedures to operate the Glo-Ray® GRHW Series mini-merchandisers. • The overhead lights will turn on, the overhead heating element will turn on, the heated glass shelf will energize, WARNING and the base heating element will energize. -
Page 10: Maintenance
2. Push the red RESET button. NOTI E: DO NOT use paper towel or glass cleaner. If the GFCI continues to trip, contact your local authorized Hatco 4. Clean the glass side panels using a standard glass cleaner Service agency. -
Page 11: Troubleshooting Guide
Overhead heat control set too high. adjust overhead heat control to a lower setting. Overhead heat control defective. Contact authorized Service agent or Hatco for assistance. Unit plugged into incorrect/high voltage. Verify that voltage supply matches electrical information listed on the unit. -
Page 12: Options And Accessories
OPTIONS AND ACCESSORIES Digital Temperature Controller Display Sign Holder a digital temperature controller option is available for a display sign holder is available as an accessory for GRHW-1SGD and GRHW-1SGDS models only. The digital GRHW-1SG, -1SGS, -1SGD, and -1SGDS models. a display temperature controller replaces the standard base heat control sign holder adds 6-1/2”... - Page 13 OPTIONS AND ACCESSORIES 4-Sided Sign Holder a 4-sided sign holder is available as an accessory for the GRHW-1SG model only. Use the following procedure to install Threaded the 4-sided sign holder. Stud 1. Remove the four upper screws from the top four corners of the unit.
-
Page 14: Limited Warranty
Hatco’s written instructions or limiting the generality of the foregoing, SUCH WaRRaNTIES 18 months from the date of shipment from Hatco. Buyer must DO NOT COVER: Coated incandescent light bulbs, fluorescent establish the Product’s purchase date by returning Hatco’s... -
Page 15: Form No. Grhwm
NOTES Form No. GRHWm-0111... -
Page 16: Authorized Parts Distributors
