SPECIFICATIONS
Engine GX31 – Petrol 31cc single cylinder OHV - 4 stroke.
Sound pressure level at operator's ears (ISO-7917):
Nylon line head 95 dB (A)
Cutting blade
87 dB (A)
Vibrations measurements at left-hand side (ISO-7916)
At idling
Nylon-line head 6.7 m/s
Cutting blade
At max throttle Nylon-line head 4.5 m/s
At racing
Cutting blade
Vibrations measurements at right-hand side (ISO-7916)
At idling
Nylon-line head 5.5 m/s
Cutting blade
At max throttle Nylon-line head 4.1 m/s
At racing
Cutting blade
IMPORTANT
PLEASE READ CAREFULLY
This machine is hired under terms & conditions of the Hire Contract.
No liability will be accepted for any damage caused to persons or
property through failure to observe operating and safety instructions.
A charge will be made for any damage caused to the machine
through misuse or failure to comply with operating instructions.
Hirers are also reminded that they are liable for the replacement cost
of any machine & accessories, lost or stolen.
BE SECURITY WISE - DO NOT TAKE ANY CHANCES
E&J HIRE
Tel: (01843) 868185
Mobile: 07745 409795
www.ejhire.co.uk
2
2
3.4 m/s
2
2
7.4 m/s
2
2
4.9 m/s
2
2
2.8 m/s
BRUSHCUTTER
HONDA 4-stroke UMK431 – 31cc
This machine is fitted with a 4-stroke petrol engine.
ONLY USE NEAT UNLEADED PETROL
(Do not use a 2-stroke oil mix)
SAFETY NOTES
ALWAYS start engine in the open air.
DO NOT smoke when refuelling.
ALWAYS stop the engine before making any adjustments,
refuelling or cleaning.
NEVER remove any safety guards that are fitted.
DO NOT touch any moving parts whilst the machine is running.
KEEP HANDS AND FEET AWAY.
BEFORE STARTING WORK clear the work area of any objects
that could damage the machine, or be thrown by cutting head.
Objects can be thrown with great force and may cause
serious injury.
NEVER allow children or anyone uninstructed to operate the
machine. KEEP CHILDREN & ANIMALS AWAY.
NEVER OPERATE MACHINE unless children, people and pets
are at least 15m (50 ft) away during operation.
WEAR adequate clothes with long sleeves and trousers, do not
wear clothes with loose tapes / laces / ribbons etc.,
PROTECTIVE DEVICES goggles, safety glasses or face shield,
helmet, earmuffs or plugs, gloves, safety boots and dust mask.
IF A FAULT or oil leak develops; do not attempt any repair – contact
E&J Hire - 01843 868185
