- Page 1 5 English Manual EN 12182 EN1021-1 EN 12183 EN1021-2 ISO 7176-19 © 2008 R82 A/S. All rights reserved. The R82 logo and the Panda Futura chairs are registered trademarks of R82 A/S. 07.2015 - rev. 005...
-
Page 2: Table Of Contents
CONTENTS Intented use ............... 3 Tools .................. 3 Declaration of conformity ........... 3 R82 Warranty ..............3 Symbols ................4 Disposal ................4 Safety ................5 Maintenance ..............6 Accessories and spare parts ..........6 Service interval ..............6 Ready for use ..............7 Mounting / dismounting of sides ........ -
Page 3: Intented Use
For further information, we refer to the R82 homepage/download. The warranty can only be sustained if the R82 product is in use in the same country where it was purchased and if the product can be identified by the serial number. The warranty does not cover accidental damage, including damage caused by misuse or neglect. -
Page 4: Symbols
Never leave the user unattended in this product Consult instructions The latest versions of the instructions are always available on the R82 website and can be printed in larger sizes Caution Incorrect use of the product may cause serious damage to the... -
Page 5: Safety
If there is any doubt as to the continued safe use of your R82 product or if any parts should fail, stop using the product immediately and contact your local dealer... -
Page 6: Maintenance
Accessories and spare parts The products from R82 can be supplied with a variety of accessories which comply with the needs of the individual user. Spare parts can be ordered on request. Find the specific accesso- ries on our website or contact your local dealer for further information. -
Page 7: Ready For Use
READY FOR USE The Panda Futura 5 seat is available as (A) STANDARD and as (B) ACTIVE. The main difference between the two models is the shaping of the seats. The ACTIVE seat is shaped to allow greater upper extremity move- ment and is ideal for more active children. -
Page 8: Back Recline
BACK RECLINE Push the handle (A) up to recline the back. To prevent sudden recline, firmly grab the back of the chair before pushing the handle. LUMBAR SUPPORT The Panda Futura 5 is delivered including adju- stable lumbar support in the back cushion. Move the lumbar support up or down (A) according to the need for support. -
Page 9: Pommel
POMMEL The Panda Futura 5 is prepared for mounting of pommel. * Fasten the mounting bracket by using the enclosed 4 mm Allen key (A). * The pommel is fitted into the bracket and is adjusted in depth by using the handle (B). SEAT EXTENSION The Panda Futura 5 is prepared for mounting of seat extension. -
Page 10: Back Extension
BACK EXTENSION The Panda Futura 5 is prepared for mounting of back extension. * Mount the bar from the back extension into the fitting on the back and fasten with the thumbscrew (A). * Loosen the thumbscrew (A) or (B) to adjust the height. -
Page 11: Side Supports
SIDE SUPPORTS The Panda Futura 5 is prepared for mounting of side supports. * Place the side supports in the slots. * Place the nuts, one by one, through the hole (A) in the back and into the slots in the side support. -
Page 12: Armrest
ARMREST Height adjustment: Open the handle (A) to move the armrest into po- sition. Place the small screw (B) in desired height position. Close the handle after adjustment. Tilting the armrest cushion: Loosen the handle (C). Adjust and angle of the armrest cushion sidewise: Loosen the screws (D) beneath the cushion. -
Page 13: Cross Vest
CROSS VEST The vest and cross vest can be opened and closed by using the buckles and the zip. * Mount the shoulder straps through the hole in the back cushion and into the fixlock fittings on the upper back (A). * Mount the upper straps in the sides in the fixlock fittings on the back (B). -
Page 14: Panda Futura 5 On High-Low:x Frame Size 2
PANDA FUTURA 5 ON HIGH-LOW:X FRAME SIZE 2 This combination must not be used for severely spastic children with vigorous movements. To mount the seat: Place the seat in the adapter and push it all the way back, until it „clicks” into place. Lock the red handle (A) to secure the stability of the seat. -
Page 15: Push Brace For High-Low:x Indoor Frame
PUSH BRACE FOR HIGH-LOW:X INDOOR FRAME Depth adjustment: Loosen the screws (A) on both sides of the frame and adjust the depth of the push brace. The push brace adjusts in two positions and clicks into place with the security nut. Fasten in the required position. -
Page 16: Panda Futura 5 On Combi Frame Size 4
PANDA FUTURA 5 ON COMBI FRAME SIZE 4 Follow the instructions below to mount an interface for Panda Futura 5 on a frame 1. Mount the interface on the frame as shown on picture (A). Fasten the interface together with the enclosed metal plates (B) on the seat base. -
Page 17: Transportation In Motor Vehicles
TRANSPORTATION The chair is approved according to ISO 7176/19-2001 and 16840-4:2009. IN MOTOR The Panda Futura 5 seat is approved for VEHICLES transporting the user in motor vehicles. Please look at MEASURES in the back of this manual for the max load. indication. The Panda Futura 5 seat on either a Combi Frame or a Multi Frame, is approved for trans- The approval is not valid on specially made... -
Page 18: Secure The Product In The Vehicle
SECURE THE PRODUCT IN THE VEHICLE * Mount the 4-point strap-type tiedown sy- stem in the vehicle. (Follow the manufacture instructions) 30° * Secure the pushchair to the vehicle, using the 4-point strap-type tiedown system. Use either a hook or a strap in the fitting. 15°... -
Page 19: Product Identification
Ver.: XX IDENTIFICATION Art.No: XXXXXX Parallelvej 3 Product - Size X DK-8751 Gedved www.R82.com Made in Denmark Panda Futura 5 seat (01)0570729530134(21)256829 A) Serial number The label is placed on the seat under the cushion. In the top right-hand corner. -
Page 20: Measures
MEASURES Panda Futura 5 Active Panda Futura 5 Standard mm (inch) mm (inch) Seat width (A) 350 (13½") 350 (13½") Seat depth (B) 430 (16¾") 430 (16¾") Back height (C) 590 (23") 590 (23") Back width, top (F2) 350 (13½") 380 (15") Back width, below (F1) 320 (12½") -
Page 21: Technical Data
The Panda Futura 5 has to be checked and tightened by a qualified technician at least every 6 months to avoid failures. Adjustments which are not described in this manual, must only be made by R82 personnel. -
Page 22: List Of Accessories
89188-5xx See page 7 89930-5 See page 9 89642-xxx See page 9 89658-xxxx See page 10 8910401-4 See page 11 89619-x See page 12 8910725-5 See page 12...
