- Page 1 ESUGS4-P1-B Quick Start Guide Rev 1912...
-
Page 2: Table Of Contents
DIN Mounting ..........................8 Wall Mounting ..........................8 Items for Attention ......................... 9 Grounding ............................9 CABLE ................................. 10 Ethernet Cable ..........................10 SFP Port ............................12 QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 2 of 12... -
Page 3: Introduction
ESUGS4-P1-B Quick Start Guide INTRODUCTION 1.1 ESUGS4-P1-B Introduction ESUGS4-P1-B is an unmanaged PoE/PoE+ industrial Ethernet switch with 4*10/100/1000M auto sensing electrical ports and 1*1000M SFP uplink port. The switch supports PoE/PoE+. Each electrical port outputs up to 30W. Industrial level 3 protection design and IP40 enclosure protection makes the product suitable for applications in harsh environments. -
Page 4: Specifications
62 x 86.5 x 100mm Weight 0.6kg Environment Storage Temperature -40 to +85℃ (-40 to 185℉) Operating Temperature -40 to +75℃ (-40 to 167℉) 5% to 95% non-condensing Operating Humidity QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 4 of 12... -
Page 5: Panel Views
4． Grounding screw 5． 10/100/1000Base-T port: #1 ~ #4 6． 1000Base-X SFP port: #5 WARNING：This product MUST be mounted to a well-groundedmounting surface such as a metal panel. QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 5 of 12... -
Page 6: Status Indicator Led
Speed indicator for 1000Mbps Green Speed indicator for 100Mbps and 10Mbps The corresponding port’s link is active LINK/ACT Orange Blinking Data is being transmitted The corresponding port’s link is inactive QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 6 of 12... -
Page 7: Dimensions (Unit:mm)
ESUGS4-P1-B Quick Start Guide DIMENSIONS (UNIT:mm) QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 7 of 12... -
Page 8: Mounting
ESUGS4-P1-B Quick Start Guide MOUNTING 4.1 DIN Mounting Very simple: Press the clamp, insert into rail then loosen hand. 4.2 Wall Mounting Step 1 Step 2 QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 8 of 12... -
Page 9: Items For Attention
Grounding and wire routing help limit the effects of noise due to electromagnetic interference (EMI). Run the ground connection from ground screw to the grounding surface prior to connecting devices. QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 9 of 12... -
Page 10: Cable
For 10/100/1000Base-T cable, pin 1 and 2 send data, pin 3 and 6 receive data. 10/100Base-T RJ-45 Pin Definition Pin Number Signal PoE+ PoE+ PoE- null null PoE- null null QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 10 of 12... - Page 11 RD+(receive) PoE+ TD-(transmit) RD-(receive) PoE+ RD+(receive) TD+(transmit) PoE- Not used Not used Not used Not used RD-(receive) TD-(transmit) PoE- Not used Not used Not used Not used QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 11 of 12...
-
Page 12: Sfp Port
(rate, MM/SM, 1 fiber/2 fibers) on need basis. Please note that 1000M SFP port supports 1000Mbps transmission rate only. Need Help? Please visit our website http://www.kbcnetworks.com or contact your nearest KBC office or dealer. QSG-ESUGS4-P1-B_Series-Rev1912 www.kbcnetworks.com Copyright © KBC Networks Networks Ltd. 2019 Page 12 of 12...
