16.1 Cables

16.1.1 Servo motor power cable

Motor end
Motor end
Name
Motor power cable
□□ stands for cable length, please refer to below.
16-2
Figure16.1.1.1 Motor power cable (HVPS04AB□□MB, without brake cable)
Figure16.1.1.2 Motor power cable (HVPS06AB□□MB, with brake cable)
Table16.1.1.1 Motor power cable for servo motor
HIWIN Part Number
HVPS04AB□□MB
HVPS06AB□□MB
□□
03
Cable Length
(m)
For 50 W ~ 750 W servo motor, without brake cable, highly
bendable
For 50 W ~ 750 W servo motor, with brake cable, highly
bendable
Table16.1.1.2
05 07
3 5 7
Servo drive end CN2
Servo drive end CN2
Description
10
10
