En plus des paramètres pouvant être
saisis à partir du panneau, les unités
sont équipées d'une série de commu-
tateurs DIP qui permettent de gérer cer-
taines options et fonctions de l'appareil.
Ne pas oublier que certaines options
pouvant être gérées à partir du pan-
neau sont liées au réglage spécifi que
de certains commutateurs DIP.
Unités
1 2
ANL OFF OFF
ANL H ON OFF
ANL C ON OFF
ANL A/Q ON OFF
ANL HA/
ON OFF
HQ
ANL Z/Y ON OFF
ANLI H ON OFF
ANR H ON OFF
ANR HA/
ON OFF
HK
ANR HP ON OFF
ANF H ON ON
ANF HA/HK/HJ ON ON
ANF HP ON ON
ANK ON ON
ANK Z/Y ON ON
ANK A ON ON
SRP ON ON
104
FR
IMDCFJ. 12.05 6343841_03
Tableau de configuration des
COMMUTATEURS DIP
Commutateur DIP (B)
Réglages par défaut du COMMUTATEUR DIP MODUCONTROL
COMMUTATEUR DIP (A)
3 4 5 6
OFF OFF ON OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON ON ON
OFF ON OFF ON
ON OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON OFF ON
OFF OFF OFF OFF
OFF OFF ON OFF
OFF ON ON ON
OFF OFF ON OFF
OFF OFF ON OFF
ON OFF OFF OFF
OFF ON ON ON
OFF ON ON OFF
Commutateur DIP (A)
7 8 9 10
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF ON
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF ON OFF
OFF OFF OFF OFF
OFF ON OFF OFF
ON OFF OFF OFF
OFF ON OFF OFF
OFF ON OFF OFF
ON ON OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF OFF OFF OFF
OFF ON OFF OFF
COMMUTATEUR
DIP (B)
11 12 1 2
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- ON OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
--- --- OFF OFF
