Summary of Contents for progressive automations flt-06
- Page 1 FLT-06 User Manual Contents Caution/Liability Page 2 Technical Specifications Page 3 Page 4 Parts/Setup Page 5 Operational/Reset Procedure, Troubleshooting Dimensions Page 6...
- Page 2 Caution Liability...
- Page 3 Technical Specifications Input Voltage 120 VAC, 60 Hz Output Voltage 24 VDC Stroke 25" Weight Capacity 350 lbs (175 lbs Per Leg) Speed 1.30"/sec Height Range 23.5” - 49” (without table top) Duty Cycle 10% Max. 2 mins on, 18 mins off Material Steel Certification...
- Page 4 Parts Control Box & Remote Connector Cables x 2 Lifting Columns x 2 AC Power Cord Setup FLT-06 FLT-06 LIFTING COLUMN [M1] LIFTING COLUMN [M2] 110/240VAC FLT-06 CONTROL BOX WIRED REMOTE...
- Page 5 Operational Procedure Once your lifting columns are installed, operation is simple. Using the wired remote will allow full control over extending and retracting the lift columns. Use the up button to raise the columns and the down button to lower the columns. You can program up to 4 locations using the memory setup: Use the up/down buttons on the remote to find your desired height(s), then press “M”...
- Page 6 Dimensions Legs 3.2" 2.8" 0.4" 2.0" M6X10 Remote 3.3" 1.4" 0.2" 2.0" 3.2" 3.4" 22.0" 2.0" ˄ ˅ M8X10 0.6" 1.6" 2.5" 0.6" 5.7" 2.2" 6.6" 2.0" M6X10 3.8" 7.6" Control Box 1.6" 0.7" 3.5" 3.5" 0.3" 0.1" 10.1"...
