Central Machinery 41889 Assembly & Operating Instructions

Central Machinery 41889 Assembly & Operating Instructions

16 inch variable speed scroll saw

Advertisement

Brought to You by Augusta Flint
16" Variable Speed
Scroll Saw
Assembly & Operating Instructions
www.HarborFreight.com
Copyright
No portion of this manual or any artwork contained herein may be reproduced in any
manner, shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
41889
41889
Model 41889
41889
41889
1999 by Harbor Freight Tools
®
. All Rights Reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 41889 and is the answer not in the manual?

Questions and answers

Summary of Contents for Central Machinery 41889

  • Page 1 Brought to You by Augusta Flint 16” Variable Speed Scroll Saw 41889 41889 Model 41889 41889 41889 Assembly & Operating Instructions www.HarborFreight.com ® Copyright 1999 by Harbor Freight Tools . All Rights Reserved. No portion of this manual or any artwork contained herein may be reproduced in any manner, shape or form without the express written consent of Harbor Freight Tools.
  • Page 2: Included Accessories

    Brought to You by Augusta Flint MODEL # 41889 16” SCROLL SAW SPECIFICATIONS Electric Motor: 380 - 1500 RPM variable speed 110V / 60Hz, double insulated Blade Speed: 350 to 1400 spm, variable speed Blade Length: 5”, pin type Throat Depth: 16”...
  • Page 3 Do not use the tool if any switch does not turn on and off properly. REPLACEMENT PARTS AND ACCESSORIES. When servicing, use only identical replacement parts, which are available from Harbor Freight Tools. Use of any other parts will void the warranty. Page 3 SKU # 41889...
  • Page 4 Repair any damage before using this tool. Be sure the blade is firmly and properly installed before use. Improperly installed blades may eject suddenly at high speed from the saw. Page 4 SKU # 41889...
  • Page 5: Basic Operation

    Keep your hands away from the saw blade while using this saw. Where possible, use a push stick to guide the workpiece into the blade, keeping your hands away. Page 5 SKU # 41889...
  • Page 6 Speed Control. Turn this knob to the right to increase saw blade speed, and to the left to reduce speed. Table Insert. This should always be in place and flush with the table during the cutting operation. Page 6 SKU # 41889...
  • Page 7: Installing The Saw Blade

    Double check to see that pins are properly located in the blade holder. Then turn the blade tension knob ONE full turn clockwise. This amount of blade tension should do well for most cutting operations and blades. Page 7 SKU # 41889...
  • Page 8 NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO. Page 8 SKU # 41889...
  • Page 9 Brought to You by Augusta Flint PARTS DIAGRAM #41889 SCROLL SAW Please see Parts Diagram on Following Page Description Description Adjustment Assembly Flat Washer Power Supply Lower Holder Spring Washer m6 Tooth Washer Hex Nut m6 Hex Head Bolt m4 x 10...
  • Page 10 Brought to You by Augusta Flint PARTS DIAGRAM #41889 SCROLL SAW Please see Parts List on Previous Page Page 10 SKU # 41889...
