ProStar
+
®
Operation and Maintenance Manual
Navistar, Inc.
2701 Navistar Drive, Lisle, IL 60532 USA
© 2015 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ProStar+ and is the answer not in the manual?

Questions and answers

Related Manuals for Navistar ProStar+

Summary of Contents for Navistar ProStar+

  • Page 1 ProStar ® Operation and Maintenance Manual Navistar, Inc. 2701 Navistar Drive, Lisle, IL 60532 USA © 2015 Navistar, Inc. All rights reserved. All marks are trademarks of their respective owners.
  • Page 2 The information, specifications, and illustrations contained in this manual are based on data that was current at the time of publication. Navistar, Inc. reserves the right to make changes and/or improvements at any time without notification, liability, or without applying those changes or improvements to vehicles previously manufactured and/or sold.
  • Page 3 These numbers are required to obtain pertinent information for this vehicle or engine. VEHICLE IDENTIFICATION NUMBER (VIN) CUSTOMER ASSISTANCE CENTER 1-800-44-TRUCK (1-800-448-7825) ENGINE Navistar, Inc. Feature Code: Serial Number: 2701 Navistar Drive Lisle, IL 60532 USA www.navistar.com FRONT AXLE Feature Code: Serial Number: REAR AXLE Feature Code:...

  • Page 5: Table Of Contents

    Table of Contents Section 1 – Foreword Engine Serial Number........16 Line Set Ticket.
  • Page 6 Table of Contents Front of Tractor..........34 Headlights.
  • Page 7 Table of Contents ® ® ® Bendix Wingman Fusion System......102 Restraint Webbing System........117 Bendix ®...
  • Page 8 Table of Contents General Information.........133 Charge Air Cooler.
  • Page 9 Indicator............183 Eaton ® Navistar ® Alliance Transmissions....163 Reservoir Moisture Draining.
  • Page 10 Table of Contents Connecting / Disconnecting a Trailer to a Vehicle Inspection and Adjustment....... . .208 with Air Suspension.
  • Page 11 Table of Contents Troubleshooting..........223 General Information.
  • Page 12 Table of Contents Maintenance Intervals........245 Fuse Charts.

  • Page 13: Section 1 - Foreword

    Foreword SECTION 1 — FOREWORD Preface Cautions and Warnings Your vehicle has been engineered and manufactured so that it Throughout this manual, you will find Cautions and Warnings: can provide economical and trouble-free service. However, it is the owner's responsibility to see that the vehicle receives proper WARNING care and maintenance.

  • Page 14: Assistance Guide

    Foreword Assistance Guide Contact Closest Navistar, Inc. Regional Sales Office. Addresses of Regional Sales Offices are found in the front When parts are required, always provide the unit code number, of this manual. Should you desire to contact any of these vehicle model, and vehicle serial number.

  • Page 15: Line Set Ticket

    Foreword Line Set Ticket NOTE: Washing Instructions - Wash the vehicle with warm water and mild soap, then wipe wet surfaces with a chamois Each vehicle is provided with a Line Set Ticket (code sheet), or soft cloth. DO NOT use hot water or strong soaps or which lists identification code numbers of component units used detergents.

  • Page 16: Storage Duration - Over One Month

    Foreword 7. Lubricate all exposed transmission, auxiliary transmission 5. Perform the procedure for Storage Duration - One Month and PTO shift rails. or Less, if returning the vehicle to storage. 8. Check state of charge eye in batteries and recharge if NOTE: After every 30 additional days of storage, perform open circuit voltage is below 12.6 volts.

  • Page 17: Diesel Exhaust Fluid (Def) Storage

    Protection Agency Noise Control Regulations. This warranty covers this vehicle as designed, built, and equipped by Navistar and is not limited to any particular part, component, or system of the vehicle manufactured by Navistar. Defects in design, assembly, or in any part, component, or system of the vehicle as manufactured by Navistar at the time the vehicle left Navistar’s control, which cause noise emissions...

  • Page 18: Tampering With Noise Control System Prohibited

    Foreword Tampering with Noise Control System Prohibited operating speed or horsepower other than those provided by Navistar, Inc. Federal law prohibits the following acts or the causing thereof: 6. Exhaust System: Removing or rendering inoperative 1. Removing or rendering inoperative by any person,...

  • Page 19: Warranty

    Foreword and the MIL will go out after certain operating conditions have The period of coverage is the greater of the base mechanical been met. This may take several times operating the vehicle. warranty or: • Five (5) years or 50,000 miles, whichever comes first, Supplemental Federal Emission Control System Warranty for spark-ignition and light heavy-duty diesel vehicles with GVWR below 19,500 pounds.

  • Page 20: Supplemental Federal Emission Control System

    National Highway Traffic Safety Administration The GHG emission-related warranty covers components (NHTSA) in addition to notifying Navistar, Inc. To notify Navistar certified as innovative technologies which are part of the certified see the contact information listed in the front of the manual.

  • Page 21: Safety Recalls And Authorized Field Changes

    Foreword ASFAD, Place de Ville Tower C, 330 Sparks Street, Ottawa, You can make the free call anonymously, and you might Ontario K1A 0N5. be eligible for a reward. To learn more about vehicle theft and how you can protect yourself, visit the NICB's Web site, www.nicb.org.
  • Page 22 Foreword • Permanently mount your CB radio or remove it when you Layer 3: Vehicle Immobilizer will be away from your truck. A. Fuse cutoffs • Do not discuss where your vehicle is located when you B. Kill switches are not on the road. C.

  • Page 23: Optional Diamond Logic Electronic Application Solutions

    Foreword ® Optional Diamond Logic Electronic Application NOTE: This vehicle may be equipped with electronic application-specific options not described in this operator’s Solutions manual. Many of these features are supplied with rocker switches that have custom labels applied. The presence of WARNING these options as factory installed can be verified from the Line Set Ticket included with the vehicle.
  • Page 24 Foreword...
