Navistar ProStar+ Operation And Maintenance Manual page 86

Controls / Features
Quadrant 2 – Display
Messages
Warn Engine (Priority 1 or 2)
Stop Hybrid
HV Batt Off-Line
Check Hybrid
Low Engine Oil Level
Change Engine Oil
Water in Fuel
Refuel
High Fuel Temp
Electrical Fault (Priority 1 or 2)
74
Description
(1) Message is displayed when the Red Stop Lamp goes
on.
(2) Message is displayed when the Amber Warning Lamp
goes on and the Red Stop Lamp does not.
Message is displayed when Hybrid system turns on and
requests the Red Stop Lamp.
Message is displayed when Hybrid system battery is off
line.
Message is displayed when Hybrid system turns on
the Amber Warning Lamp while conditions for "HV Batt
Off-Line" message are not met.
Message is displayed when engine oil level is less than
or equal to 80%.
Message is displayed when engine oil change is detected
as necessary.
Message is displayed when water in fuel is present.
You should drain water from fuel / water separator.
Message is displayed when fuel level is low.
Message is displayed when fuel temp is high.
(1) Message is displayed when when EGC requests the
Red Stop Lamp.
(2) Message is displayed when when EGC requests the
Amber Warning Lamp.
Message Flashes (Yes Warning Indicator
/ No) Association
Yes (1) Red Stop Lamp
(2) Amber Warning Lamp
Yes Red Stop Lamp
Yes No
Yes Amber Warning Lamp
Yes No
Yes No
Yes No
Yes No
Yes No
Yes (1) Red Stop Lamp
(2) Amber Warning Lamp
