View The Readme File; Visit Order Assistant - HP NetServer LC 3 Installation Road Map

3
Set Up NetServer
1. Mount the HP NetServer on the pedestal.
to install the HP NetServer in a rack assembly, wait until after
you install all optional accessories and replace covers.
The instructions molded into the pedestal point toward the front
of the pedestal and show the centerline.
Use them to center the HP NetServer so its front extends 2
inches (5 cm) beyond the front of the pedestal.
Then push the HP NetServer in toward the rear of the pedestal
until it locks into place. See illustration at right.
2. Connect cables : Connect the monitor, keyboard, and mouse to
the HP NetServer, and plug in the power cords to the HP
NetServer and to the monitor.
3. Connect Optional Uninterruptible Power Supply (UPS).
Refer to the instructions supplied with the UPS if you have one.
4
Prepare for Hardware Installation
NOTE Two different CD-ROMs are shipped with the
system. Make sure you have selected the
CD-ROM that includes HP NetServer Navigator.
1. Boot the HP Navigator CD-ROM:
on the HP NetServer, and eject the CD-ROM drive. Place the HP
Navigator CD-ROM in the drive, and close the drive. Turn off the
NetServer power, wait 10 seconds, and turn on the power again.
If the system fails to boot, follow the instructions on the screen.
When HP Navigator starts, you can change its language, set the
time and date, and change the BIOS language.
2.

View the Readme file:

Navigator Main Menu. The Readme file contains the latest
information to help you install your HP NetServer.
3. Run Diagnostic Assistant (optional):
NetServer hardware as shipped, run Diagnostic Assistant from
the HP Navigator CD-ROM. Select "NetServer Utilities" from the
HP Navigator Main Menu, and then select "Diagnostic Assistant"
from the NetServer Utilities menu.
5
Remove the Covers
To prepare to install memory, accessories, and boards, do the
following:
Turn off the NetServer and disconnect the power cord.
Remove the front bezel and top cover.
If you are installing accessory boards or a non-hot-swap mass
storage device, also remove one side cover.
To install some options, you will need a flat 1/4-inch screwdriver
®
and T15 TORX driver.
WARNING Before removing the cover, disconnect
the power cord and unplug telephone
cables. Disconnect the power cord to
cut standby power and reduce shock
hazards. Disconnect telephone cables
to eliminate shock hazard from
telephone ringing voltages.
1. Unlock the front bezel
located on the rear of the HP NetServer. Remove the front bezel
by pulling on the pocket in the side of the bezel to swing that side
outward, and then pull the bezel off.
2. Remove the top cover:
front of the top cover forward 1/16 inch (1.5 mm).
3. Lift the front of the top cover
1 inch (3 cm), but no more, between the front of the top cover
and the top of the chassis. Push the top cover back, and lift it off.
CAUTION Lifting the top cover higher than 1 inch
(3 cm) can damage it and the chassis.
4. Remove the side cover, if needed:
from the system board, grasp the two tabs at the top of the
cover, pull upward and outward, and lift the cover off.
CAUTION Wear a wrist strap and use a static-
dissipating work surface connected to the
chassis when handling components.
All manuals and user guides at all-guides.com
However, if you plan
Turn on the monitor. Power-
Select "Readme File" from the HP
To verify the HP
key lock with the key in the key bag
Loosen both thumbscrews. Pull the
up enough to create a gap of
On the side cover farthest
Rear View
Mouse Connector
Keyboard Connector
Monitor Connector
Power Connector
Pedestal
4. Install Information Assistant:
of online documentation for the HP NetServer. IA provides
information to help install your NetServer. It is easier to use from
another system, rather than the one you are installing. Install
Information Assistant onto the client system that you use to
manage your HP NetServer. To do so, insert the HP NetServer
Online Documentation CD-ROM, run Windows. From the
Program Manager, select the file menu, choose run, and enter
drive:\infoasst\setup where "drive" is the letter of the CD drive.
5. Visit Order Assistant (optional)
http://www.hp.com/netserver
third-party components that have been tested and found to work
with your HP NetServer. It also lists HP accessories, cables, and
connectors for your HP NetServer.
6. Obtain IntranetWare key (optional):
optional IntranetWare software that came with your HP
NetServer, purchase the software and obtain the key before
beginning NOS installation in Step 11: "Configure the HP
NetServer." Use the key request form in the HP NetServer
Software Option Package.
Front
Bezel
Pocket
Key Lock
1
Thumbscrews
Unlocked Position
1 inch
(3 cm)
3
Information Assistant (IA) is a set
on the Internet at
. Order Assistant lists HP and
If you plan to install the
Top
Cover
2 2
System Tabs
Board
Side
Cover
4
