IKA STARVISC 200-2.5 control Manual page 14

Viscosity:
Density:
In order to measure the kinematic viscosity of a certain medium, the
user need to input the density of the medium. Changing the density
by rotating knob (B).
Stirrer:
Before measuring the kinematic viscosity, select a proper stirrer tool.
Meanwhile, set the correct stirrer tool accordingly in the menu op-
tion by rotating knob (B).
Definition of the viscosity range:
VLV (Very Low Viscosity)
LV (Low Viscosity)
MV (Medium Viscosity)
HV (High Viscosity)
Measuring condition:
Propeller stirrer: R 1345
Suitable for measuring viscosity range
(mpa·s):
HV: 10000 up to 100000
Optimum speed (rpm) and permissible
speed range in viscosity range:
HV: 200 (50 ... 300)
Measuring error max.: ± 13%.
Sample volume: 1000 ml
Necessary beaker: HF 2000 DIN 12331
2000 ml, high shape.
Measuring condition:
Dissolver stirrer: R 1302
Suitable for measuring viscosity
range (mpa·s):
HV: 10000 up to 100000
Optimum speed (rpm) and per-
missible speed range in viscosity
range:
HV: 200 (50 ... 400)
Measuring error max.: ± 12%.
Sample volume: 1500 ml
Necessary beaker: HF 3000
DIN 12332 3000 ml, low shape.
mpa·s
1 ... 100 Aqueeous media
100 ... 1000 Light oil
1000 ... 10000 Heavy oil
10000 ... 100000 Pastes, creams
1000 ml
120 mm
1500 ml
150 mm
Measuring condition:
Paddle stirrer: R 1375
Suitable for measuring viscosity range (mpa·s):
HV: 10000 up to 100000
Optimum speed (rpm) and permissible speed
range in viscosity range:
HV: 100 (50 ... 250)
Measuring error max.: ± 16%.
Sample volume: 600 ml
Necessary beaker: HF 800
DIN 12331 800 ml, high shape.
Measuring condition:
Anchor stirrer: R 1330
Suitable for measuring viscosity range (mpa·s):
HV: 10000 up to 100000
Optimum speed (rpm) and permissible speed
range in viscosity range:
R 1345
HV: 300 (100 ... 400)
Measuring error max.: ± 5%.
Sample volume: 200 ml
Necessary beaker: HF 250
DIN 12331 250 ml, high shape.
Measuring condition:
Anchor stirrer: R 1331
Suitable for measuring viscosity range
(mpa·s):
HV: 10000 up to 100000
Optimum speed (rpm) and permissible
speed range in viscosity range:
HV: 300 (50 ... 300)
Measuring error max.: ± 4%.
Sample volume: 1700 ml
Necessary beaker: HF 2000
DIN 12331 2000 ml, high shape.
R 1302
Display:
When you need to show the viscosity on the screen, you need ac-
tive the "Display" under "Viscosity" menu option and meanwhile
deactivate one of "Torque", "Temperature" or "Timer" display.
R 1375
600 ml
86 mm
R 1330
200 ml
62 mm
R 1331
1700 ml
120 mm
