IKA STARVISC 200-2.5 control Manual page 8

Securing the mixing vessel to the stand
Diagram (see Fig. 7)
First fix the cross sleeve (H) to the stand (I).
Then attach the bracket (Z) of the strap clamp in the open side of
the cross sleeve which is facing upwards according to the position
of stirrer and the mixing vessel, firmly tighten the two clamping
bolts (G).
Clamp the mixing vessel (V) with the flexible clamping band (W) and
secure the flexible band (W) by means of the clamping lever (X).
Securing the WiCo to the stirrer
Diagram (see Fig. 1)
Attach the WiCo to the charging contact provided on the station,
and bolt it to the station with the screw (P).
Connection of the temperature sensor, USB and RS232
cables to the stirrer
Diagram (see Fig. 6)
The USB, RS 232 or temperature sensor cable should be plugged
into the appropriate port after the covers have been removed as
shown in Fig. 6.
Once the device has been connected to the PC using the USB data
cable, it will then transmit information to the Windows operating
system to tell it which device drivers are required. Windows will
then either:
- Load the driver
- Install the driver automatically, if it is not already installed
- Prompt you to perform a manual installation
Open http://www.ika.com/ika/lws/download/usb-driver.zip.
Charging the RB 1 battery pack (rechargeable battery)
The battery pack of the WiCo can be charged by any of the fol-
lowing means:
- on the station
- via a USB cable at the PC or station
- via an OS 1.0 power supply unit.
Replacing the RB 1 battery pack in the Wireless Controller
Please comply with the relevant safety
NOTICE
instructions in the "Safety instructions"
section for the RB 1 battery pack!
8
