Model:
BE-41
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Printed in U.S.A. Copyright 2000,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
All manuals and user guides at all-guides.com
1
GUIDE
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Heat-N-Glo dealer for any
questions or concerns. For the number of your
nearest Heat-N-Glo dealer, please call 952-985-6000.
Installers Guide
Underwriters
Laboratories Listed
INSTALLERS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Heat-N-Glo BE-41 and is the answer not in the manual?

Questions and answers

Summary of Contents for Hearth Technologies Heat-N-Glo BE-41

  • Page 1 Printed in U.S.A. Copyright 2000, Please contact your Heat-N-Glo dealer for any questions or concerns. For the number of your Heat-N-Glo, a division of Hearth Technologies Inc. 20802 Kensington Boulevard, Lakeville, MN 55044 nearest Heat-N-Glo dealer, please call 952-985-6000. This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;...
  • Page 2: Safety And Warning Information

    All manuals and user guides at all-guides.com SAFETY AND WARNING INFORMATION These units MUST use one of the vent systems READ and UNDERSTAND all instructions carefully described in the Installing the Fireplace section of before starting the installation. FAILURE TO the Installers Guide.
  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com TABLE OF CONTENTS Safety and Warning Information ..........2 Service Parts Lists ..............4 Section 1: Approvals and Codes ..........6 Approval Listings and Codes ............6 Appliance Certification..............6 Installation Codes ................6 High Altitude Installations ...............
  • Page 4: Service Parts Lists

    All manuals and user guides at all-guides.com Service Parts BE-41 (NG, LP) Exploded Parts Diagram / Vue éclatée des pièces Log Set Assembly...
  • Page 5 All manuals and user guides at all-guides.com BE-41 Service Parts List / Liste des pièces de rechange ITEM / STANDING PILOT AND DSI IGNITION COMMON PARTS SERIAL # / N° PART NUMBER PIÈCE / UNE VEILLEUSE ET ALLUMAGE DSI PIÉCES COMMUNES DE SÉRIE / N°...
  • Page 6: Section 1: Approvals And Codes

    All manuals and user guides at all-guides.com Approvals and Codes High Altitude Installations Appliance Certification Installers Guide Certification Installation Codes Heat-N-Glo Quality Systems registered by SGS ICS...
  • Page 7: Section 2: Getting Started

    All manuals and user guides at all-guides.com Getting Started Introducing the Heat-N-Glo Gas Fireplaces Installers Guide Pre-install Preparation Installers Guide...
  • Page 8 All manuals and user guides at all-guides.com 28 1/2 [724mm] 14 ¼ [362mm] 21 1/2 [548mm] 8 5/8 [219mm] 11 5/8 [297mm] 8 5/8 VENT COLLARS ELECTRICAL [219mm] ACCESS VENT COLLARS GAS LINE ACCESS 34 5/8 25 ¼ [879mm] [965mm] [642mm] 24 5/8 2 1/8...
  • Page 9: Section 3: Installing The Fireplace

    All manuals and user guides at all-guides.com Installing the Fireplace Step 1. Locating the Fireplace Vertical Sections Horizontal Sections At Wall Firestops 42” 22” 36” 51” 72”...
  • Page 10: Step 2 Framing The Fireplace

    All manuals and user guides at all-guides.com Step 2. Framing the Fireplace CAUTION: MEASURE FIREPLACE DIMENSIONS AND VERIFY FRAMING METHODS AND WALL COVERING DETAILS BEFORE FRAMING. Shows center of 12” x 12” vent framing SHOWS CENTER OF12" X 12" holes for top and rear venting. The center VENT FRAMING HOLES FOR of the hole is one (1) inch (25.4mm) above TOP &...
  • Page 11 All manuals and user guides at all-guides.com 6 7/16” (164mm) 8 1/2” (216mm) 8 1/2” (216mm) 11 1/16” 7 3/8” 5 7/8” (281mm) (187mm) (149mm) 6 1/2” 5 1/16” (165mm) (129mm) 8 5/8” 8 5/8” (220mm) (220mm) 11 15/16” (303mm) DV-90D DV-48D DV-36D...
  • Page 12: Step 3 Installing The Vent System

    All manuals and user guides at all-guides.com Step 3. Installing the Vent System Installers Guide VERTICAL TERMINATION STORM COLLAR ROOF FLASHING HORIZONTAL HORIZONTAL PIPE TERMINATION SUPPORT PIPE LENGTH WALL FIRESTOP CEILING WALL BRACKET FIRESTOP 90 DEGREE ELBOW DVK-01D DVK-TVCD DVK-01TRD...
  • Page 13 All manuals and user guides at all-guides.com HORIZONTAL VENTING Kit No. H Max. Run DVK-01D DVK-01TRD 24" (610 mm) STRAIGHT UP 90-DEGREE ELBOWS 45-DEGREE ELBOW 5” EXHAUST PIPE VERTICAL BAFFLE CENTER VERTICAL BAFFLE ON 5” EXHAUST PIPE...
  • Page 14 All manuals and user guides at all-guides.com 1' MIN. (305mm) 2' MAX. (610mm) 2' MIN. (610mm) 4' MAX. (1.22m) 3' MIN. (914mm) 6' MAX. (1.86m) 4' MIN. (1.22m) 8' MAX. (2.4m) V+H=40' MAX. (12.4m) H = 8' MAX. (2.4m)
  • Page 15 All manuals and user guides at all-guides.com VENTING WITH TWO (2) 90° ELBOWS H + H 1´ MIN. (305 mm) 2´ MAX. (610 mm) 5´ MAX. (1.52m) 2´ MIN. (610 mm) 4´ MAX. (1.22 m) 10´ MAX. (3.1m) 3´ MIN. (914 mm) 6´...
  • Page 16 All manuals and user guides at all-guides.com H + H 1´MIN. (305mm) 2´MAX. (610mm) 5´MAX. (1.52m) 2´MIN. (610mm) 4´MAX. (1.22m) 10´MAX. (3.1m) 3´MIN. (914mm) 6´MAX. (1.86m) 15´MAX. (4.65m) 4´MIN. (1.22m) 8´MAX. (2.48m) 20´MAX. (6.2m) +V+H+H = 40 MAX.(12.4 m) H = 8´MAX.(2.48 m) H+H = 20´MAX.(6.2 m) ´...
  • Page 17 All manuals and user guides at all-guides.com NOTE:...
  • Page 18: Installing Vent Components

    All manuals and user guides at all-guides.com B. Installing Vent Components STARTING COLLAR STOVE SEALANT BEAD FIRST VENT COMPONENT 1 INCH (25.4mm) Venting Out Top Venting Out Rear SEAL SEAL HEAT INSULATION SHIELD DISCARD BOTH PIECES and HEAT SHIELD HEAT SHIELD DISCARD INSULATION...
  • Page 19 All manuals and user guides at all-guides.com WALL BRACKET WALL STUD 8 FT. (2.4m) FLUE OUTLET 1 INCH MIN. (25.4mm) NOTE: Model DVK-01TRD does not need an exterior firestop on an exterior combustible wall. NOTE: The center of the hole is one (1) inch (25.4mm) above the center of the horizontal vent pipe.
  • Page 20 All manuals and user guides at all-guides.com 12" (305mm) 12" (305mm) 1" (25.4 mm) VENT PIPE 11" (280 mm) 11" (280mm) CHIMNEY HOLE HEAT SHIELD TRIM HEAT SHIELD IF TOO EXISTING CEILING JOISTS LONG, ADD TO FRAMING SHIELD IF TOO MEMBERS SHORT CEILING...
  • Page 21: Vent Termination

    All manuals and user guides at all-guides.com JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP NOTE: Keep insulation away from the vent pipe at least 1 inch (25mm). ROUND CAP TERMINATION NAILS (4 REQUIRED) PERFORATION CANNOT BE INSIDE THE WALL RAFTER 7 1/2"...
  • Page 22 All manuals and user guides at all-guides.com openable fixed closed J or K 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS NECESSARY TO INSTALL THE VINYL PROTECTOR KIT TO THE TOP OF THE EXTERIOR FIRESTOP (FOR ALL ROUND TERMINATION CAPS).
  • Page 23 All manuals and user guides at all-guides.com HORIZONTAL OVERHANG 2 FT. 2 FT. MIN. VERTICAL MIN. WALL LOWEST DISCHARGE OPENING TERMINATION ROOF PITCH IS X/ 12 H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING NOTE: This also pertains to vertical vent systems in- stalled on the outside of the building.
  • Page 24: Step 5 The Gas Control Systems

    All manuals and user guides at all-guides.com Step 4. Positioning, Leveling, and Step 5. The Gas Control Systems Securing the Fireplace Standing Pilot Ignition...
  • Page 25: Step 6 The Gas Supply Line

    All manuals and user guides at all-guides.com Step 6. The Gas Supply Line Step 7. Gas Pressure Requirements Pressure requirements for Heat-N-Glo gas fireplaces are shown in the table below. Pressure Natural Gas Propane Minimum 5.0 inches 11.0 inches Inlet Pressure w.c.
  • Page 26: Step 8 Wiring The Fireplace

    All manuals and user guides at all-guides.com BLACK S2 WHITE T2 RED T1 THERMOPILE OPTIONAL REMOTE GAS VALVE OPTIONAL WALL SWITCH BLACK S1 Step 8. Wiring the Fireplace CAUTION: DISCONNECT REMOTE CONTROLS IF AB- SENT FOR EXTENDED TIME PERIODS. THIS WILL PREVENT ACCIDENTAL FIREPLACE OPERATION.
  • Page 27: Step 9 Finishing

    All manuals and user guides at all-guides.com Step 9. Finishing FINISH WALL MATERIAL MAY BE DRYWALL - TOP AND SIDES CEILING 12" HIGH TEMPERATURE (300 F/149 C MIN.) 11" TOP & SIDE SEAL JOINT 10" 9" 31” 8" 7" 6" 12”...
  • Page 28 All manuals and user guides at all-guides.com BEFORE FIRING THE UNIT Follow these steps: 1. Release four glass clips and set the glass assembly aside. CAUTION: The log assembly is fragile. Handle with care. NOTE: See Step 9 when replacing the log set in an existing fireplace.
  • Page 29 All manuals and user guides at all-guides.com 5. The grate is located in the lower cav- ity. Remove the screw holding the grate in place and discard the screw. 6. Position the grate into the cutout in the refractory. Hook the grate into po- sition using the tabs on the bottom of the grate.
  • Page 30: Placing The Ember Material

    All manuals and user guides at all-guides.com Step 11. Before Lighting the Fireplace Installers Guide Step 12. Lighting the Fireplace After the Installation CAUTION: IT IS STRONGLY RECOMMENDED THAT TRIM DOORS WITH OPTIONAL MESH SCREENS BE IN- STALLED ON PROPANE MODELS.
  • Page 31: Section 4: Maintaining And Servicing Your Fireplace

    All manuals and user guides at all-guides.com Maintaining and Servicing Your Fireplace Fireplace Maintenance MAKE SURE THE FLAMES ARE STEADY—NOT LIFTING OR FLOATING.
