HP Velotechnik GO SwissDrive Operating Instructions

HP Velotechnik recumbents with
Dear customer,
The original GO SwissDrive operating in-
structions describe all specifications offe-
red.
These supplementary instructions give
you an overview of the variants that can
be used with HP Velotechnik as well as
additional installation instructions.
This manual does not replace the original
GO SwissDrive manual, but complements
it.
Please also refer to the original HP Velo-
technik operating manual for your recum-
bent model.
Pushing aid backwards
HP Velotechnik tricycles are equipped
with the reverse gear. It is activated by
pressing and holding the[-] key in driving
mode (cf. chapter 6.1. Using the grip con-
trols).
Light
Depending on the headlamp model instal-
led, the light is switched on automatically
together with the electric drive system or
separately on the headlamp.
The light on HP Velotechnik recumbents
cannot be switched on and off via the GO
SwissDrive display.
GO SwissDrive
Display languages:
You can select the languages German, En-
glish or French on the display. (See chap-
ter 6.3.1 System settings)
In the event of a tyre defect or to service
Removing the rear wheel
the shift components, it may be necessary
to remove the rear wheel.
Before removing a rear wheel, please
read the corresponding chapters of
your general bicycle operating instruc-
tions. If you are unsure or have ques-
tions, contact your dealer.
Since the engine is installed in the rear
wheel, proceed as follows:
1.Turn off the system at the control and
disconnect the plug from the battery.
2. After disconnecting the battery, turn
the display on and off again while the rear
wheel is stationary to completely de-
energize the system.
3. Set up the pedelec so that the rear
wheel can be removed. Ideally, you should
clamp it in an appropriate mounting stand.
Due to the high weight of your pedelec, it
makes sense to lift the bike together with
a second person.
HP VELOTECHNIK GmbH & Co. KG
Phone +49 61 92 - 97 99 2-0
Fax +49 61 92 - 97 99 22 99
E-mail mail@hpvelotechnik.com
Internet www.hpvelotechnik.com
Danger!
Kapellenstrasse 49
65830 Kriftel Germany
●
