COP-USA TCDFE6MIP-9568 User Manual

Network fisheye camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Network FishEYE
Camera
User Manual
Please read this instruction carefully before using the product and preserve it for further
reference

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TCDFE6MIP-9568 and is the answer not in the manual?

Questions and answers

Related Manuals for COP-USA TCDFE6MIP-9568

Summary of Contents for COP-USA TCDFE6MIP-9568

  • Page 1 Network FishEYE Camera User Manual Please read this instruction carefully before using the product and preserve it for further reference...
  • Page 2 Notes on Safety  Please use the specified power supply to connect.  Do not attempt to disassemble the camera; in order to prevent electric shock, do not remove screws or covers.  There are no user-serviceable parts inside. Please contact the nearest service center as soon as possible if there is any failure.

  • Page 3: Table Of Contents

    Table of Contents Introduction ........................1 IE Remote Access ......................3 LAN ..............................3 2.1.1 Access through IP-Tool ....................3 2.1.2 Directly Access through IE ..................... 4 WAN ............................... 6 Live View ........................9 Remote Configuration ....................13 System Configuration........................13 4.1.1 Basic Information ......................
  • Page 4 Network Camera User Manual Maintenance Configuration ......................33 4.7.1 Backup and Restore ...................... 33 4.7.2 Reboot .......................... 34 4.7.3 Upgrade ........................34 4.7.4 Operation Log ....................... 35 Search ........................... 36 Photo Search ..........................36 Video Search ..........................37 5.2.1 Local Video Search ....................... 37 5.2.2 SD Card Video Search ....................

  • Page 5: Introduction

    Network Camera User Manual 1 Introduction The network fisheye camera which adopts high-definition fisheye lens and high performance image sensor can meet 360°all-around high definition surveillance requirements. With the advanced H.265/H.264 video compression technology, high compression rate, accuracy and stable stream control, the camera ensures higher quality image and less occupancy of storage space.
  • Page 6 Network Camera User Manual Installation Recommended Distance:...

  • Page 7: Ie Remote Access

    Network Camera User Manual 2 IE Remote Access You may connect IP-Cam via LAN or WAN. Here only take IE browser (6.0) for example. The details are as follows: 2.1 LAN In LAN, there are two ways to access IP-Cam: 1. access through IP-Tool; 2. directly access through IE browser.

  • Page 8: Directly Access Through Ie

    Network Camera User Manual For example, the IP address of your computer is 192.168.1.4. So the IP address of the camera shall be changed to 192.168.1.X. After modification, please input the password of the administrator and click “Modify” button to modify the setting. ...
  • Page 9 Network Camera User Manual HTTP: 80 Data port: 9008 You may use the above default settings when you log in the camera for the first time. You may directly connect the camera to the computer through network cable. ① Manually set the IP address of the PC and the network segment should be as the same as the default settings of the IP camera.

  • Page 10: Wan

    Network Camera User Manual ② Open the IE browser and input the default address of IP-CAM and confirm. The IE browser will download Active X control automatically. ③ After downloading Active X control, you will see a login dialog box. ④...
  • Page 11 Network Camera User Manual IP Setup ③ Go to the router’s management interface through IE browser to forward the IP address and port of the camera in the “Virtual Server”. Router Setup ④ Open the IE browser and input its WAN IP and http port to access. (for example, if you change your http port as 81, you may input “192.198.1.201:81”...
  • Page 12 Network Camera User Manual ① Go to ConfigNetworkPort menu to set the port number. ② Go to Config NetworkTCP/IPPPPoE Config menu. Enable PPPoE and then input the user name and password which you can get from your internet service provider. ③...

  • Page 13: Live View

    Network Camera User Manual 3 Live View After you log in, you will see the following window. Before you view the live image, please set the stream mode and installation method as required (see Set Fisheye Parameters for details). In the live mode, you can switch different streams and live preview modes, capture live images, enable live audio and record, etc.
  • Page 14 Network Camera User Manual  In full screen mode, double click to exit. Click to select the live view mode. Fisheye view mode: See the picture as shown above. Panoramic view mode Fisheye+ 3PTZ view mode Panoramic + 3PTZ view mode...
  • Page 15 Network Camera User Manual 4PTZ view mode (you need to switch the stream mode in the fisheye parameter interface) In panoramic + 3PTZ view mode or fisheye + 3PTZ view mode or 4PTZ view mode, select a PTZ window and view the image from every direction by controlling PTZ panel. Click to unfold the control panel.
  • Page 16 Network Camera User Manual Icon Description Icon Description Click it to rotate the dome Click it to rotate the dome diagonally up-left diagonally up-right. Click it to rotate the dome Click it to stop rotating the dome. upwards. Click it to rotate the dome Click it to rotate the dome towards left towards right.

  • Page 17: Remote Configuration

    Network Camera User Manual 4 Remote Configuration 4.1 System Configuration The “System” configuration includes four submenus: Basic Information, Date and Time, Local Config and Storage. 4.1.1 Basic Information In the “Basic Information” interface, you can check the relevant information of the device. 4.1.2 Date and Time Go to ConfigSystemDate and Time.

  • Page 18: Local Config

    Network Camera User Manual 4.1.3 Local Config Go to ConfigSystemLocal Config. You can set the storage path of the captured pictures and video records. You can also enable or disable the video audio. 4.1.4 Storage Go to ConfigSystemStorage to go to the interface as shown below. The first time you use the SD card, you should click “Format”...

  • Page 19: Set Fisheye Parameters

    Network Camera User Manual Go to ConfigSystemStorageRecord to go to the interface as shown below. You can set the SD card record stream. Set the pre record time if you enable pre record. Click “Save” button to save the settings. Pre Record Time: Set the time to record before the actual recording begins.
  • Page 20 Network Camera User Manual Brightness: Set the brightness level of the camera’s image. Contrast: Set the color difference between the brightest and darkest parts. Hue: Set the total color degree of the image. Saturation: Set the degree of color purity. The purer the color is, the brighter the image is. Sharpness: Set the resolution level of the image plane and the sharpness level of the image edge.

  • Page 21: Video / Audio Configuration

    Network Camera User Manual Day/night Mode: Please choose the mode as needed. Sensitivity: High, middle and low can be selected. Infrared Mode: You may choose “ON”, “OFF” and “Auto” as required. Exposure Mode: You may choose “Auto” or “Manual” as required. 4.2.2 Video / Audio Configuration Go to ImageVideo / Audio interface as shown below.

  • Page 22: Osd Configuration

    Network Camera User Manual image quality you choose, the more bitrate will be required. I Frame interval: It is recommended to use the default value. If the value is over high, the read speed of the group of pictures will be slow resulting in the quality loss of the video. Video Compression: H264 and H265 are optional.

  • Page 23: Roi Configuration

    Network Camera User Manual To set up video mask: 1. Enable video mask. 2. Click “Draw Area” button and then drag the mouse to draw the video mask area. 3. Click “Save” button to save the settings. 4. Return to the live to see the following picture. Clear the video mask: Go to video mask interface and then click “Clear”...

  • Page 24: Ptz Configuration

    Network Camera User Manual 1. Check “Enable” and then click “Draw Area” button. 2. Drag the mouse to set the ROI area. 3. Set the level. 4. Click “Save” button to save the settings. Now, you will see the selected ROI area is clearer than other areas especially in low bitrate condition.

  • Page 25: Alarm Configuration

    Network Camera User Manual 4.4 Alarm Configuration Alarm configuration includes four submenus: Motion Detection, Alarm In, Alarm Out and Alarm Server. 4.4.1 Motion Detection Go to AlarmMotion Detection to set motion detection alarm. 1. Check “Enable Alarm” check box to activate motion based alarm, choose alarm holding time and set alarm trigger options.
  • Page 26 Network Camera User Manual Move the “Sensitivity” scroll bar to set the sensitivity. Select “Add” and click “Draw” button and drag mouse to select the motion detection area; Select “Erase” and drag the mouse to clear motion detection area. After that, click “Save” to save the settings. 3.

  • Page 27: Alarm In

    Network Camera User Manual means one day of a week; the rank means 24 hours of a day. Green means selected area. Blank means unselected area. “Add”: Add the schedule for a special day. “Erase”: Delete holiday schedule. Day schedule Set alarm time for alarm in some time of a special day, such as holiday.

  • Page 28: Alarm Out

    Network Camera User Manual 4.4.3 Alarm Out Go to ConfigAlarmAlarm Out interface as shown below: Select alarm holding time at the “Alarm Holding Time” pull down list box. Click “On” to trigger alarm out. Click “off” to stop alarm out. Click “Save”...

  • Page 29: Port

    Network Camera User Manual address automatically by DHCP protocol and use the following IP address. Please choose one of the options for your requirements. Use PPPoE-Click “PPPoE Config” tab to go to the interface as shown below. Enable PPPoE and then enter the user name and password from your ISP. You can choose either way of the network connection.

  • Page 30: Server Configuration

    Network Camera User Manual Data Port: The default data port is 9008. Please change it as required. RTSP Port: The default port is 554. Please change it as required. 4.5.3 Server Configuration This function is mainly used for connecting network video management system. 1.

  • Page 31: Snmp

    Network Camera User Manual Create domain name. After you successfully request your domain name, you will see your domain in the list. 3. Input the username, password, domain you apply for in the DDNS configuration interface. 4. Click “Save” button to save the settings. 4.5.5 SNMP To get camera status, parameters and alarm information and remotely manage the camera, you can set the SNMP function.

  • Page 32: Rtsp

    Network Camera User Manual Port” and so on. Please make sure the settings are the same as that of your SNMP software. Note: Please use the different version in accordance with the security level you required. The higher the version is, the higher the level of the security is. 4.5.6 RTSP Go to ConfigNetworkRTSP.

  • Page 33: Upnp

    Network Camera User Manual 1. Select “Enable”. 2. RTSP Port: Access port of the streaming media. The default number is 554. 3. RTSP Address: The RTSP address is what you need to input in the media player. You shall input it in the media player according to the format listed above. 4.

  • Page 34: Ftp

    Network Camera User Manual Sender Address: sender’s e-mail address. User name and password: sender’s user name and password. Server Address: The SMTP IP address or host name. Select the secure connection type at the “Secure Connection” pull-down list according to actual needs.

  • Page 35: Security Configuration

    Network Camera User Manual Server Name: The name of the FTP. Server Address: The IP address or domain name of the FTP. Upload Path: The path of uploading the files. Port: The port of the FTP. Use Name and Password: The username and password are used to login the FTP. 4.6 Security Configuration 4.6.1 User Configuration Go to ConfigSecurityUser interface as shown below.
  • Page 36 Network Camera User Manual 2. Input user name in “User Name” textbox. 3. Input letters or numbers in “Password” and “Confirm Password” textbox. 4. Choose the use type. Administrator has all permissions. Common user can only view the live image. Compared administrator, advanced user cannot set user, backup settings, restore the system to the default factory settings and upgrade the software.

  • Page 37: Online User

    Network Camera User Manual Delete user: 1. Select the user you want to delete in the user configuration list box. 2. Click “Delete” button to delete the user. Note: The default super administrator cannot be deleted. 4.6.2 Online User Go to ConfigSecurityOnline User. You can view the user who is viewing the live video. 4.6.3 Block and Allow Lists Go to ConfigSecurityBlock and Allow Lists interface as shown below.

  • Page 38: Reboot

    Network Camera User Manual  Import & Export Settings You can import or export the setting information from PC or to device. 1. Click “Browse” to select save path for import or export information on PC. 2. Click “Import Setting” or “Export Setting” button. ...

  • Page 39: Operation Log

    Network Camera User Manual 4.7.4 Operation Log To query and export log: 1. Go to ConfigMaintenanceOperation Log. 2. Select the main type, sub type, start and end time. 3. Click “Search” to view the operation log. 4. Click “Export” to export the operation log.

  • Page 40: Search

    Network Camera User Manual 5 Search 5.1 Photo Search Click SearchPhoto to go to the interface as shown below. You can search the images saved in the SD card. Set time: Select date and choose the start and end time in the top left corner. Check events.

  • Page 41: Video Search

    Network Camera User Manual Icon Description Icon Description Slide show play: Click this Stop: Click this button to stop button to play the picture in slide slide show. show mode. Play speed: Play speed of the slide show. 5.2 Video Search 5.2.1 Local Video Search Click SearchVideoLocal Video to go to the interface as shown below.

  • Page 42: Sd Card Video Search

    Network Camera User Manual Icon Description Icon Description Click it to enable / disable Full screen. Click it to audio; drag the slider to display full screen. adjust the volume after Double click to exit enabling audio. full screen. 5.2.2 SD Card Video Search Click SearchVideoSD Card Recording to go to the interface as shown below.

  • Page 43: Appendix

    Network Camera User Manual Appendix Appendix 1 Q & A Q: How to find my password if I forget it? A：Reset the device to the default factory settings. Default IP: 192.168.226.201; User name: admin; Password: 123456 Q：Fail to connect devices through IE browser, why? A: Network is not well connected.
  • Page 44 Network Camera User Manual Q：No sound can be heard, why? A：Audio input device is not connected. Please connect and try again. B: Audio function is not enabled at the corresponding channel. Please enable this function.

  • Page 45: Appendix 2 Specifications

    Network Camera User Manual Appendix 2 Specifications Specification /Model Network IR Fisheye Camera Image Sensor 1/2.9＂CMOS Image Size 2160× 2160 Electronic Shutter 1/25s~1/100000s Lens 1.07mm@F2.5, horizontal field of view:180° (wall mounting ), 360° (ceiling mounting) Camera Day&Night Digital WDR Support Support Digital NR 3D DNR...
