- Page 1 Standalone G-Converter: MTU200-N64M June 2000 Rev 1.0 Standalone G-Converter G.703/G.704 to Nx64 X.21/V.35 Converter TECHNICAL: (0118) 965 6000 SALES: (0118) 965 5100 FAX: (0118) 965 5001 ADDRESS: 464 Basingstoke Road, Reading, Berkshire RG2 0QN WEB: www.blackbox.co.uk...
- Page 2 Standalone G-Converter How To Contact your Local Black Box Italy: Australia: Black Box Italia S.P.A Black Box Catalog Australia PTY LTD Tel: 0227400280 Tel: 0398797100 Fax: 0227400219 Fax: 0398702955 Web Site: www.blackbox.it Deutschland: Brazil: Black Box Deutschland Black Box Do Brasil.
- Page 3 Fax: 0145606747 Fax: 724-746-0746 Web Site: www.blackbox.fr Web Site: www.blackbox.com Spain: Chile Black Box Comunicaciones S.A. Black Box Chile Tel: 34 91 663 0200 Tel: 00 562 223 8811 Fax: 34 91 661 84 35 Fax: 00 562 225 1002 Web Site: www.blackbox.es...
- Page 4 Standalone G-Converter Standalone G-Converter G.703/G.704 to Nx64 X.21/V.35 Converter User Manual WARNING - BEFORE INSTALLATION, PLEASE REFER TO SAFETY INSTRUCTIONS IN APPENDIX A, AND EMC INSTRUCTIONS IN APPENDIX C Certified Compliant in the EC, when fitted in accordance with the installation instructions, against the following directives/standards: Low Voltage Directive (73/23/EEC and amendment 93/68/EEC) EN60950...
-
Page 5: Table Of Contents
Standalone G-Converter Contents Introduction ..............................7 Local Control..........................7 Remote Control...........................7 Operating Modes .............................8 Operating Mode 1 ........................8 Operating Mode 2 ........................8 Operating Mode 3 ........................9 Operating Mode 4 ........................9 G.703 Interface Presentation .........................10 75 ohm operation ........................10 120 ohm operation ........................10 Selection and Configuration Of DCE Interface..................11 X.21/V.11 Interface ........................11 Control Of “I”... - Page 6 Standalone G-Converter Appendix –B Approval Requirements ....................26 G.703/G.704 ..........................26 Appendix C – EMC Requirements ......................27 Limitation of Emissions: ......................27 'D-Type' Connections....................27 Appendix D -Location Of Switches and Links ..................28 Appendix E - G.703 Interface Pin Outs ....................29 Appendix F - RJ45 E1 Crossover Cable ....................30 Appendix G- X.21/V.11 DCE Pinout.......................31 Appendix H –...
-
Page 7: Introduction
Standalone G-Converter Introduction This manual provides information covering installation and set-up procedures of the converter. A full set of cable pin-outs and a PCB layout (showing the location of switches and link settings) are included in the appendices. The G-Converter is an interface adapter that will convert between a G.703/G.704 link and an X.21/V.11 or V.35 interface. -
Page 8: Operating Modes
Standalone G-Converter Operating Modes The equipment has four operating modes: Refer to the Switch and link location diagram in Appendix D -Location Of Switches and Links. Operating Mode 1 G.703 Transparent interface converter, data rate fixed at 2048kbps, Remove the cover of the unit, locate Internal Switch 4 and set as follows: SW4,1 SW4,2 SW4,3... -
Page 9: Operating Mode 3
Standalone G-Converter Operating Mode 3 G.703 Interface, data rate configurable between 0bps and 1984kbps Remove the cover of the unit, locate Internal Switch 4 and set as follows: SW4,1 SW4,2 SW4,3 SW4,4 SW4,5 SW4,6 SW4,7 SW4,8 N.B. NR = Not Relevant. When converters are to be set up as a pair, one unit MUST be configured as a Local unit (SW4, 1 = Off) and the other a Remote unit (SW4, 1=On) The external Loop switch (front panel) should be set as Normal. -
Page 10: Interface Presentation
Standalone G-Converter G.703 Interface Presentation The converter may be configured to operate on either a 120 ohm balanced circuit impedance, presented on an RJ45 connector or with a 75 ohm unbalanced impedance, presented on two BNC connectors. Selection of the interface is made by link settings – refer to Appendix D -Location Of Switches and Links for the location diagram and use in conjunction with the tables below. -
Page 11: Selection And Configuration Of Dce Interface
Standalone G-Converter Selection and Configuration Of DCE Interface The DCE port of the G-Converter can be presented as either X.21/V.11 or V.35 Choice of interface is made by link setting. The X.21/V.11 interface is presented on a 15-way D type connector in accordance with ISO 4903. -
Page 12: Configuration Of V.35 Control Flags
Standalone G-Converter The G-Converters support one input flag and two output flags. It is up to the user which of the signals is to be implemented. RTS would normally be the definition for Flag 1 I/P (although is does not have to be) as this is the only I/P called up by the V.35 spec. The two output flags, Flag 2 O/P and Flag 3 O/P can be assigned to either CTS, DSR or DCD, the choice is at the discretion of the user. -
Page 13: Remote Loopback Function
Standalone G-Converter Remote Loopback Function If the stand-alone G-Converter has SW5, 1 to off, the Manager card located in the card cage may select a remote loopback. Once this state has been entered, it will remain in loopback for approximately 3 minutes. Whilst in loop back, the LED display will flash “rL”, the data and clock being outputted through the DCE port will be suppressed and the data arriving at the X.21/V.35 drivers/receivers will be looped back to the central site. -
Page 14: External Clock
Standalone G-Converter External Clock The G-Converters have the ability to use as its clock source a clock supplied from the connected DTE. An external clock is supplied externally to the converter via the EXT clock pins, of the 15 way D type connector (pins 7 and 14). Whenever an external clock is used, the rightmost decimal point of the seven-segment display is illuminated. -
Page 15: Configuration
Standalone G-Converter Configuration Configuration of the G-Converters is achieved in two simple stages involving internal and external switches, and setting of some internal links. Refer to Appendix D -Location Of Switches and Links for details of Internal Switch and link locations. Selection of internal links permit the converters to operate either as a Local or Remote unit. -
Page 16: Dil Switch Settings
Standalone G-Converter DIL switch settings The mode of operation is set up using the DIL switches SW4 and SW5. SW POSITION FUNCTION SETTING SW4, 1 Selects either remote Off = local operation or local operation On = remote SW4, 2 Selects interface type Off = G.703 On = G.704... -
Page 17: Default Unit Set-Up
Standalone G-Converter Notes: Only allow unframed operation if a DCE speed of 2048Kbps will not “harm” the DTE. Use this mode if no in-band management is required and the link is required to run a permanent 2048Kbps. Also, use this mode if interfacing to another manufacturers G.703/X.21 interface converter. -
Page 18: Front Panel Led Indicators
Standalone G-Converter Front panel LED indicators The G-Converter has 4 LED indicators: - LED LABEL CONDITION NOTES CARRIER RX Carrier established No RX Carrier established. LOOP Either a Local loop or a remote loop mode has been entered. (check position of loop control switch SW) Normal Operation ERROR... -
Page 19: Diagnostics
Standalone G-Converter Diagnostics Front Panel LEDs On the front panel, only the CARRIER LED and POWER should normally be illuminated. When the G-Converter is disconnected from the network or has lost carrier the CARRIER LED will extinguish. Seven Segment Display The seven segment LED display can reveal the state of the G-Converter. - Page 20 Standalone G-Converter A BERT tester configured, as a DTE capable of generating test patterns should be connected to the “DCE” port of the G-Converter. With the link interface disconnected, the LOOP switch on the energised G-Converter set to Local, the BERT tester will detect the clock being generated by the G-Converter and if the unit is operating correctly the looped back data should be error free.
-
Page 21: Installation
Standalone G-Converter Installation Before installation, please refer to the safety warnings, approvals requirements and EMC requirements in the appendices. Supply Voltage and Connection 240V AC. The Converter is AC powered by a “plug in” switched mode power supply that is provided with the unit. -
Page 22: Back-To-Back Demonstration Connection
Standalone G-Converter Back-To-Back Demonstration Connection For a simple demonstration, or local network use, two converters may be connected ‘back to back’, using a cross over cable arrangement, one unit will automatically adopt the role of clock master the other clock slave. 75 ohms BNC to PD7024 interfaces For UK interfaces a pair of 75 Ohm BNC cables should be used, connecting TX on one unit to RX on the other and visa versa. -
Page 23: Appendix A - Warnings
Standalone G-Converter Appendix A - Warnings WARNING: THIS EQUIPMENT MUST BE EARTHED/ GROUNDED VIA THE SCREEN OF THE X.21 DTE LEAD This equipment relies on the EARTH/GROUND connection to ensure EMC compliance. It must not under any circumstances be operated without an earth connection, which could nullify its approval. - Page 24 Standalone G-Converter WARNUNG: ZUR EINHALTUNG DER EMC BESTIMMUNGEN MUSS DIESES GERÄT ÜBER SCHIRM X.21 SCHNITTSTELLE GEERDET WERDEN. DAS GERÄT DARF NICHT OHNE DIESE ERDUNG BETRIEBEN WERDEN. G-Converter wird einer externen Stromversorgungseinheit versorgt – diese ist nur für die Verwendung zusammen mit einem G-Converter Konverter geprüft.
- Page 25 Standalone G-Converter CET ÉQUIPEMENT DOIT ÊTRE RELIÉ A LA MISE EN GARDE: TERRE/MASSE PAR LE BLINDAGE DU FIL DTE X.21 Pour garantir la conformité EMC de cet équipement, il doit impérativement relié à TERRE/MASSE. En aucun cas, il ne doit être utilisé...
-
Page 26: Appendix -B Approval Requirements
Standalone G-Converter Appendix –B Approval Requirements The G-Converter carrying the BABT/CE168 assessment symbols and approval number, is approved for connection to the networks identified in this Appendix as follows: G.703/G.704 In the UK, to PD7024 (75 Ohm Un-balanced) via 2 x BNC connectors. The internal jumper links must be set to the 75R position, as detailed in the installation instructions. -
Page 27: Appendix C - Emc Requirements
This product relies on the use of screened cables for connection to the 15 way 'D-Type' ports. The cables must have the foil or braid screen connected effectively to the metal headshell to ensure continued compliance. These headshells are available from Black Box under the following part numbers:... -
Page 28: Appendix D -Location Of Switches And Links
Standalone G-Converter Appendix D -Location Of Switches and Links SALES: 0118 965 5100... -
Page 29: Appendix E - G.703 Interface Pin Outs
Standalone G-Converter Appendix E - G.703 Interface Pin Outs COMPOSITE INTERFACE CONNECTIONS (EUROPE) USING 120 OHM BALANCED RJ45 Name Description Type at Connector DTE – RJ45 Female RX Pair Input RX Pair Input TX Pair Output TX Pair Output Shield Reference Shield Reference COMPOSITE INTERFACE CONNECTIONS (UK) USING 75 OHM UN-BALANCED BNC... -
Page 30: Appendix F - Rj45 E1 Crossover Cable
Standalone G-Converter Appendix F - RJ45 E1 Crossover Cable RJ45 CROSSOVER CABLE (EUROPE) USING 120 OHM BALANCED RJ45 Name Description DTE2 – RJ45 Male DTE1 – RJ45 Male TxRxA TXRX Pair TxRxB RxTxA RXTX Pair RxTxB Shield Reference Shield Reference Notes: Link strap must be fitted in 120 position and not in 75 position. -
Page 31: Appendix G- X.21/V.11 Dce Pinout
Standalone G-Converter Appendix G- X.21/V.11 DCE Pinout 15 Way D Type female Configured as DCE DATA CHANNEL CONNECTIONS Name Description Type at Connector DCE – DB15 Female Protective Ground Signal Ground T(A) TxDa Input T(B) TxDb Input R(A) RxDa Output R(B) RxDb Output... -
Page 32: Appendix H - V.35 Dce Pinout
Standalone G-Converter Appendix H – V.35 DCE Pinout 15 Way female D type configured as DCE DATA CHANNEL CONNECTIONS Number Name Type at Connector DCE – DB15 Female Protective Ground Signal Ground Bidirectional See note 1 Flag 3 I/P V.28 Input ExtClk(A) V.11 Input ExtClk(B) -
Page 33: Appendix I - V.35 Stub Cable
Standalone G-Converter Appendix I – V.35 Stub Cable V.35 Stub cable 15 way D type Name Type MRAC 34 pin connector Male Female Protective Ground Shield Signal Ground Bidirectional RTS(Flag 3 I/P) V.28 Input ExtClk(A) V.11 Input ExtClk(B) V.11 Input RXClk(A) V.11 Output RXClk(B)
