- Page 1 Instructions Important Safety Instructions Read all warnings and instructions in this manual and in the sprayer operation manual. Save these instructions. Lacquer Conversion Kit 256212 312933A ti11870a...
- Page 2 Lacquer Conversion Kit 256212 Ref. Part No. Description Qty. 117559 O-RING, CV-75, size 020 111507 O-RING, CV-75, size 013 111316 O-RING, CV-75, size 012 15D370 O-RING, CV-75, size 022 15D371 O-RING, CV-75, size 015 15D252 O-RING, CV-90, size 008 119400...
- Page 3 Instructions 7. Install base (C) on valve, aligning pin (E) on base (C) with hole (F) on manifold. 1. To relieve pressure: a. Turn power switch to OFF. b. Unplug sprayer. c. Turn knob (A) down to PRIME/DRAIN. d. Hold metal part of gun firmly to a grounded metal pail.
- Page 4 All written and visual data contained in this document reflects the latest product information available at the time of publication. Graco reserves the right to make changes at any time without notice. This manual contains English. MM 312933 Graco Headquarters: Minneapolis International Offices: Belgium, China, Japan, Korea GRACO INC.
