Furrion FCR14ACBQA-BL Instruction Manual page 10

Installation
Fig. 2
4. Pull on the top of the exhaust vent
towards you and lift to remove it from the
refrigerator. (Fig. 3 and Fig. 4) Pull on
both left and right sides to remove the
bottom intake vent from the refrigerator.
(Fig. 5)
Fig. 3
Fig. 4
9
Fig. 5
5. Put the refrigerator completely into the
enclosure. (Fig. 6) Make sure to leave
115/16" (50mm) minimum space from the
1 / "
1
2 back of the refrigerator to the cabinet for
35.0 mm
better air circulation. (Fig. 7)
Fig. 6
