- Page 1 GRUNDFOS INSTRUCTIONS MP 204 Safety instructions and other important information Installation and operating instructions http://net.grundfos.com/qr/i/96650480...
- Page 2 Cleaning and user maintenance shall not be made by children without supervision. Hazard statements The symbols and hazard statements below may appear in Grundfos installation and operating instructions, safety instructions and service instructions. DANGER Indicates a hazardous situation which, if not...
- Page 3 The hazard statements are structured in the following way: Intended use SIGNAL WORD MP 204 is an electronic motor protector, designed for the protection of an asynchronous motor or a pump. Description of hazard It must always be installed in a cabinet.
- Page 4 Mechanical installation Electrical connections DANGER DANGER Electric shock Electric shock Death or serious Death or serious personal injury personal injury - Before starting any - All cables taken work on the product, through the product make sure that the and the current power supply has been transformers must be switched off and that it...
- Page 5 "5" to MP 204 must be protected separately with maximum 10 A fuses. wiring polarity matches If current transformers are used, the L1-L2-L3 and the installation "5" to MP 204 must be protected with maximum 10 A fuses. instructions. WARNING Cause of fire...
- Page 6 The connections to L1, L2, L3 and "5" can be made with a cable of up to 10 mm . A special fuse unit up to approximately 50 A is therefore not required. Maximum 10 A MP 204 Pt100 Pt100/Pt1000 Fig. 1 Three-phase connection...
- Page 7 Three-phase system with external current transformers Maximum 10 A MP 204 Pt100 Pt100/Pt1000 Fig. 2 Three-phase connection with current transformers Fig. 3 Five windings per phase through MP...
- Page 8 Single-phase system with start and run capacitors start MP 204 Pt100/Pt1000 Pt100 Fig. 4 Single-phase connection...
- Page 9 This product or parts of it must be disposed of in an environmentally sound way: Pump operation with MP 204 1. Use the public or private waste collection service. DANGER 2. If this is not possible, contact the nearest Grundfos company or service workshop.
- Page 10 Appendix 中国 RoHS (Pb) (Hg) (Cd) (Cr6+) (PBB) (PBDE) SJ/T 11364 GB/T 26572 GB/T 26572...
- Page 11 We, Grundfos, declare under our sole responsibility that the product Ние, фирма Grundfos, заявяваме с пълна отговорност, че MP 204, to which the declaration below relates, is in conformity with продуктът MP 204, за който се отнася настоящата декларация, the Council Directives listed below on the approximation of the laws отговаря...
- Page 12 MP 204, me të cilin ka lidhje kjo deklaratë, është në pajtim me ج المنتMP 204، ال ذي يخت ص ب ه اإلق رار أدن اه، يك ون مطابق ا direktivat e Këshillit të renditura më poshtë për përafrimin e ligjeve të...
- Page 13 Руководство по эксплуатации ЕАС...
